Honda CB1000CA (83) 1000 CUSTOM, JPN, VIN# 1HFSC100-DA000001 TO 1HFSC100-DA007620 FINAL GEAR CASE COVER Diagram

#

Description
Price

1

RUBBER, L. SIDE COVER MOUNTING (NOT AVAILABLE)

11364-425-000

Unavailable

2

COVER, FINAL GEAR CASE (NOT AVAILABLE)

11375-461-750

Unavailable

3

O-RING, FINAL GEAR CASE COVER (NOT AVAILABLE)

11376-461-000

Unavailable

4

PROTECTOR, FINAL GEAR CASE COVER (NOT AVAILABLE)

11377-461-000

Unavailable

5

PLATE, PROTECTOR SETTING (NOT AVAILABLE)

11378-461-000

Unavailable

6

PLATE A, OIL PASSAGE (NOT AVAILABLE)

11379-461-000

Unavailable

7

GEAR SET, REDUCTION (NOT AVAILABLE)

23510-461-305

Unavailable

8

GEAR, REDUCTION DRIVE (47T) (NOT AVAILABLE)

23511-461-750

Unavailable

9

GEAR, REDUCTION SUB-DRIVE (43T) (NOT AVAILABLE)

23512-461-010

Unavailable

10

COLLAR, SPLINE (48MM) (NOT AVAILABLE)

23514-461-000

Unavailable

11

COLLAR, SPLINE (28X14.1) (NOT AVAILABLE)

23515-461-000

Unavailable

12

SHAFT, SHIFT FORK (NOT AVAILABLE)

23516-461-000

Unavailable

13

SHIFTER, REDUCTION GEAR (NOT AVAILABLE)

24271-461-010

Unavailable

14

SPRING, SHIFT DRUM STOPPER (NOT AVAILABLE)

24435-461-000

Unavailable

15

STOPPER, GEARSHIFT DRUM (NOT AVAILABLE)

24438-461-000

Unavailable

16

SPINDLE, GEARSHIFT (NOT AVAILABLE)

24615-461-000

Unavailable

17

PUMP ASSY., OIL (NOT AVAILABLE)

25100-461-003

Unavailable

18

WASHER, ROTOR SETTING (NOT AVAILABLE)

31105-003-000

Unavailable

19

BOLT, GEARSHIFT DRUM STOPPER ARM PIVOT This part replaces 90023-041-000.

90023-041-010

$2.25

19

BOLT, GEARSHIFT DRUM STOPPER ARM PIVOT

90023-041-010

$2.25

20

BOLT, FLANGE (8X52) (NOT AVAILABLE)

90063-461-000

Unavailable

21

BOLT, FLANGE (8X82) (NOT AVAILABLE)

90064-461-000

Unavailable

22

BOLT, FLANGE (8X90) (NOT AVAILABLE)

90065-461-000

Unavailable

23

BOLT, SPECIAL (8MM) (NOT AVAILABLE)

90067-461-000

Unavailable

24

BOLT, SEALING (8MM)

90109-371-000

$2.58

25

WASHER, THRUST (28MM)

90451-461-000

Unavailable

26

WASHER, STOPPER (28MM) (NOT AVAILABLE)

90468-461-000

Unavailable

27

WASHER (36MM) (NOT AVAILABLE)

90469-461-000

Unavailable

28

WASHER (8MM)

90471-580-000

$2.92

29

CAP, OIL (NOT AVAILABLE)

90472-461-750

Unavailable

30

BOLT, FLANGE (12X15)

90473-461-000

Unavailable

31

PIN, DOWEL (10X46) (NOT AVAILABLE)

90706-461-000

Unavailable

32

BEARING, RADIAL BALL (6205) (NOT AVAILABLE)

91013-461-000

Unavailable

33

OIL SEAL (12X24X5) (NOK) This part replaces 91203-436-003.

91203-436-004

$6.16

33

OIL SEAL (12X24X5) (NOK)

91203-436-004

$6.16

34

O-RING (11.9X2.2)

91370-461-000

$2.39

35

SCREW, PAN (6X6) This part replaces 93500-06006.

93500-06006-0A

$1.49

35

SCREW, PAN (6X6)

93500-06006-0A

$1.49

36

SCREW, PAN (6X10) This part replaces 93500-06010.

93500-06010-0A

$1.49

37

WASHER, DRAIN PLUG (12MM)

94109-12000

$1.49

38

CIRCLIP (OUTER) (36MM)

94510-36000

$1.92

39

CIRCLIP (INNER) (38MM)

94520-38000

$2.30

40

BOLT, FLANGE (6X50) This part replaces 95700-06050-00.

95701-06050-00

$2.06

40

BOLT, FLANGE (6X50)

95701-06050-00

$2.06

41

BEARING, RADIAL BALL (6204)

96100-62040-00

$12.22
