Honda CA110A MOTORCYCLE, JPN, VIN# CA110-100001 FRONT WHEEL Diagram

#

Description
Price

1

RIM, WHEEL This part replaces 42701-001-053.

42701-001-073

Unavailable

1

RIM, WHEEL This part replaces 42701-001-063.

42701-001-073

Unavailable

1

RIM, FR. WHEEL

42701-001-073

Unavailable

2

AXLE, FR. WHEEL

44301-GN2-000

Unavailable

2

AXLE, FR. WHEEL This part replaces 44301-011-640.

44301-GN2-000

Unavailable

3

COLLAR, FR. SIDE WHEEL (NOT AVAILABLE) | Use from Frame SN 71416

44311-011-000

Unavailable

4

HUB, FR. WHEEL

44601-011-000

Unavailable

5

SPOKE A, FR.

44618-001-020

Unavailable

6

COLLAR, FR. DISTANCE AXLE | Use from Frame SN 5971416

44620-001-010

Unavailable

7

TIRE, FR. (2.25-17) (NITTO) (NOT AVAILABLE) | Use from Frame SN 414083

44711-001-680

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 0Y400-03010.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 08400-03010.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 42712-041-003.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE)

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 42712-052-009.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 42712-148-610.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 42712-148-672M2.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 44712-001-000.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 44712-030-000.

42712-041-154

Unavailable

8

TUBE, TIRE (2.50-17) (INOUE) This part replaces 44712-169-005.

42712-041-154

Unavailable

9

FLAP, TIRE (2.15-17) (BS)

42713-MG7-003

$7.75

9

FLAP, TIRE (2.15-17) (BS) This part replaces 44713-001-000.

42713-MG7-003

$7.75

9

FLAP, TIRE (2.15-17) (BS) This part replaces 44713-030-000.

42713-MG7-003

$7.75

10

GEAR, SPEEDOMETER (NOT AVAILABLE)

44806-011-010

Unavailable

11

CABLE ASSY., SPEEDOMETER | Use from Frame SN 197444 to 49317

44830-GF4-000

$23.38

11

CABLE ASSY., SPEEDOMETER | Use from Frame SN 197444 to 493417

44830-GF4-000

$23.38

11

CABLE, SPEEDOMETER (NOT AVAILABLE) | Use from Frame SN 100001 to 197443

44830-011-000

Unavailable

11

CABLE ASSY., SPEEDOMETER | Use from Frame SN 197444 to 49317 This part replaces 44830-011-010.

44830-GF4-000

$23.38

11

CABLE ASSY., SPEEDOMETER | Use from Frame SN 197444 to 493417 This part replaces 44830-011-010.

44830-GF4-000

$23.38

11

CABLE ASSY., SPEEDOMETER | Use from Frame SN 197444 to 493417 This part replaces 44831-011-010.

44830-GF4-000

$23.38

12

PANEL, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 1000001 to 120775

45100-011-000

Unavailable

12

PANEL, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 200542 to 493417

45100-011-020

Unavailable

13

SHOE, BRAKE (N/A: USE P/N 451A0-001-670)

45120-001-010

Unavailable

14

CAM, BRAKE (NOT AVAILABLE)

45131-001-010

Unavailable

15

SPRING, BRAKE SHOE This part replaces 45133-001-010.

45133-028-000

$2.03

15

SPRING, BRAKE SHOE

45133-028-000

$2.03

16

CAP, FR. BRAKE PANEL DUST SEAL (NOT AVAILABLE)

45142-011-000

Unavailable

17

RING, FR. BRAKE PANEL FELT (NOT AVAILABLE)

45143-011-000

Unavailable

18

ARM, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 394100 to 493417

45410-001-030

Unavailable

19

LINK, FR. BRAKE (NOT AVAILABLE)

45431-001-000

Unavailable

20

NUT, FR. BRAKE ARM SETTING | Use from Frame SN 394100 to 493417

45436-001-000

$1.80

21

SPACER, FR. BRAKE PANEL | Use from Frame SN 1000001 to 123041

55141-011-000

Unavailable

21

SPACER, FR. BRAKE PANEL (NOT AVAILABLE) | Use from Frame SN 123042 to 493417

55141-011-010

Unavailable

22

BOLT, FR. BRAKE PANEL STOPPER (NOT AVAILABLE) | Use from Frame SN 305671 to 493417

90104-011-000

Unavailable

23

BOLT, FR. BRAKE TORQUE (NOT AVAILABLE) | Use from Frame SN 305671 to 493417

90126-011-000

Unavailable

24

NUT, AXLE (NOT AVAILABLE)

90305-001-000

Unavailable

25

NUT, SELF-LOCK (8MM)

90349-001-000

$2.83

26

WASHER (8.5MM) | Use from Frame SN 305671 to 493417

90521-259-000

$1.92

27

PIN, COTTER (2.0X35) This part replaces 94201-20250.

94201-20350

$1.49

27

PIN, COTTER (2.0X35) This part replaces 94201-20280.

94201-20350

$1.49

27

PIN, COTTER (2.0X35) This part replaces 94201-20320.

94201-20350

$1.49

27

PIN, COTTER (2.0X35)

94201-20350

$1.49

28

WASHER, RR. BRAKE ARM | Use from Frame SN 394100 to 493417

90525-001-000

$1.95

29

WASHER (8.3MM) | Use from Frame SN 305671 to 493417

90534-011-000

$1.49

30

OIL SEAL (45X58X7) This part replaces 91251-001-020.

91251-001-023

Unavailable

30

OIL SEAL (45X58X7)

91251-001-023

Unavailable

31

OIL SEAL (21X35X7) (NOT AVAILABLE)

91252-011-000

Unavailable

33

BEARING, RADIAL BALL (6202U)

96140-62020

$13.60

34

SPOKE A (12X162)

97351-21164-10

$3.21

34

SPOKE A (12X162) This part replaces 97351-21164-12.

97351-21164-10

$3.21
