Polaris CA TOURING CRUISER ALL OPTIONS - V05TB16 SUSPENSION, STRUT and HANGER MOUNTING - V05TB16/ALL OPTIONS (4996279627B06) Diagram

#

Description
Price

1

Pad, Rubber

5811941

$6.59

2

Strut, LH

1013951-067

$150.79

2

Strut, RH

1013952-067

$129.37

3

Bushing, Fender, Rear, Silver

5133702

Unavailable

4

Screw

7518155

Unavailable

5

SCR-HXFL-M8X1.25X20 10.9 ZPB

7517838

$4.35

5

SCR-HXFL-M8X1.25X20 10.9 ZPB

7517838

$4.35

6

Asm., Cover Strut, LH [Incl. Clips]

1013641

$253.97

6

Asm., Cover Strut, RH [Incl. Clips]

1013642

Unavailable

6

Clip, Strut

7670139

$6.35

7

Screw

7517887

$2.38

8

Washer

7556164

$2.99

8

Washer

7556164

$2.99

9

Bracket, Luggage Rack

5246681

Unavailable

10

Screw

7517888

$11.60

11

SCREW

7517951

$5.56

12

Hanger, Rear

1012963-067

$77.78

13

Fender, Rear, Black

1013164-266

$834.99

13

Fender, Rear, Sonic Blue

1013164-341

$939.99

13

Fender, Rear, Solar Red

1013164-342

$939.99

13

Fender, Rear, PWH

1013164-352

$939.99

13

Fender, Rear, Midnight Blue Metallic

1013164-469

$939.99

14

Nut, Hex

7547076

$2.60

15

Kit, Rack

2874780

Unavailable
