Honda C70A (83) PASSPORT, JPN, VIN# JH2DA010-DS300004 TO JH2DA010-DS308543 HANDLEBAR + TOP BRIDGE Diagram

GROMMET, THROTTLE CABLE (NOT AVAILABLE)

17911-179-700

Unavailable

PLATE, FORK TOP (NOT AVAILABLE)

51102-086-720

Unavailable

HANDLEBAR *R110* (MONZA RED) (NOT AVAILABLE)

53100-GB5-670ZC

Unavailable

HANDLEBAR *NH44MS* (SPECIAL SILVER METALLIC) (NOT AVAILABLE)

53100-GB5-670ZD

Unavailable

HANDLEBAR *PB121MS* (SHUTTLE BLUE METALLIC-S)

53100-GB5-670ZE

Unavailable

COVER, HANDLEBAR (LOWER) *R110* (MONZA RED) (NOT AVAILABLE)

53120-GB5-670ZC

Unavailable

COVER, HANDLEBAR (LOWER) *NH44MS* (SPECIAL SILVER METALLIC) (NOT AVAILABLE)

53120-GB5-770ZA

Unavailable

COVER, HANDLEBAR (LOWER) *PB121MS* (SHUTTLE BLUE METALLIC-S) (NOT AVAILABLE)

53120-GB5-770ZB

Unavailable

COVER, HANDLEBAR (LOWER) *R110* (MONZA RED) (NOT AVAILABLE)

53120-GB5-770ZC

Unavailable

PLUG, HANDLE COVER (LOWER)

53125-174-670

$1.84

PLATE, FORK TOP BRIDGE (NOT AVAILABLE)

53231-GB5-670

Unavailable

SEAT A, FORK TOP BRIDGE RUBBER (NOT AVAILABLE)

53232-172-010

Unavailable

SEAT B, TOP BRIDGE RUBBER (NOT AVAILABLE)

53233-172-000

Unavailable

COLLAR, STEERING STEM (NOT AVAILABLE)

53234-171-000

Unavailable

WASHER, TOP BRIDGE (NOT AVAILABLE)

53235-086-010

Unavailable

COLLAR, TOP BRIDGE

53236-171-000

$2.43

WASHER, FORK TOP BRIDGE SEAT (NOT AVAILABLE)

53237-172-000

Unavailable

BOLT, FLANGE (8X32) This part replaces 95800-08032-00.

95801-08032-00

$2.07

BOLT, FLANGE (8X32)

95801-08032-00

$2.07

WASHER, HANDLEBAR MOUNT (NOT AVAILABLE)

90518-086-000

Unavailable

WASHER, TOOTHED

90552-001-000

Unavailable

BOLT-WASHER (8X16)

93401-08016-00

$1.75

BOLT-WASHER (8X16) This part replaces 93411-08016-00.

93401-08016-00

$1.75

BOLT-WASHER (8X16) This part replaces 93481-08016.

93401-08016-00

$1.75

BOLT-WASHER (8X16) This part replaces 93481-08016-00.

93401-08016-00

$1.75

NUT, HEX. (8MM)

94001-08000-0S

$1.49

WASHER, SPRING (8MM)

94111-08000

$1.49

NUT C, STEERING STEM

95020-13100

Unavailable
