Honda C125A2AC (22) MOTORCYCLE, THA, VIN# MLHJA585-N5000001 TO MLHJA585-N5099999 RIGHT CRANKCASE COVER Diagram

COVER, R. CRANKCASE

11330-K0G-T30

$68.78

CLAMP A, OIL TEMP SENSOR CORD

11346-KTR-940

$0.78

PROTECTOR, R. COVER

11371-K0G-T30

$38.65

GASKET, R. CRANKCASE COVER (NICHIAS)

11394-K1M-T02

Unavailable

CLIP, PISTON PIN (13MM)

13115-GN5-910

$0.71

COVER, OIL FILTER

15411-K0G-T30

$21.75

ELEMENT, OIL FILTER

15412-MGS-D21

$7.80

SPRING, OIL FILTER

15414-MEB-670

$2.43

DIPSTICK, OIL

15651-K2J-T00

$2.50

RUBBER, MOUNTING

19639-GBC-000

$1.29

LEVER, CLUTCH

22810-K0G-T20

$31.84

PLATE

22823-K0G-T20

$5.72

SPRING, CAM PLATE SIDE

22825-KWB-600

$0.54

SPRING, CAM PLATE SIDE This part replaces 22825-KWW-740.

22825-KWB-600

$0.54

PLATE, CLUTCH LIFTER

22830-K0G-T20

$8.66

BOLT, CLUTCH ADJ.

22846-K1M-T00

$1.00

RETAINER, BALL

22860-K1M-T00

$4.04

COLLAR, TAILLIGHT SETTING

33715-GB0-900

$2.71

BOLT, FLANGE (6X18)

90001-K0G-T20

$1.01

BOLT, FLANGE (6X35)

90004-K0G-T20

$1.01

SCREW, PAN (6X18)

90130-K26-900

$0.85

WASHER (8MM)

90485-K1M-T00

$1.00

BEARING, NEEDLE (1010) (TOYO)

91021-148-004

$22.74

O-RING (39.8X2.2) (ARAI)

91302-PA9-003

$4.66

O-RING (8MM)

91303-001-010

$2.24

O-RING (18X3)

91307-KRM-840

$0.76

NUT, HEX. (8MM)

94030-08000

Unavailable

PIN, DOWEL (8X14) (Honda Code 0069310)

94301-08140

$2.76
