Kawasaki BRUTE FORCE® 750 LE EPS Steering Shaft Diagram
#
Description
Price
11056
BRACKET,STRG,UPP
11056-0284
$10.58
11056A
BRACKET,EPS BODY FIT
11056-0285
$47.92
11056B
BRACKET,EPS ECU
11056-0290
$16.98
14092
COVER,EPS
14092-0260
$34.28
14092A
COVER,EPS,CAP
14092-0261
$6.78
16172
ACTUATOR,EPS
16172-0049
$1,656.19
21175
CONTROL UNIT-ELECTRONIC,EPS
21175-1927
$863.51
39114
SHAFT-COMP-STRG
39114-0309
$108.94
92009
SCREW,6X20
92009-1289
$4.31
92015
NUT,FLANGED,6MM
92015-1367
$3.69
92022
WASHER,8.2X19X2
92022-1533
$5.52
92027
COLLAR,L=12
92027-1062
$7.34
92049
SEAL-OIL,SR31.8X37.5X3.8LR
92049-7501
$5.00
92072
BAND,BATTERY
92072-3879
$35.74
92075
DAMPER,9X24X14
92075-281
$6.22
92139
BUSHING,STRG SHAFT
92139-0763
$13.36
92152
COLLAR,6.3X8.3X7.2
92152-1865
$1.19
92160
DAMPER
92160-1895
$3.09
92161
DAMPER
92161-0586
$2.34
92171
CLAMP
92171-0225
$1.97
92173
CLAMP,STRG SHAFT
92173-0746
$16.35
92200
WASHER,6.5X20X1.6
92200-0283
$1.40
92200A
WASHER,10.5X25X1.6
92200-1595
$6.18
92210
NUT,FLANGED,LOCK,8MM
92210-0493
$7.60
130
BOLT-FLANGED,6X30
130BA0630
$1.46
130A
BOLT-FLANGED,8X16
130BA0816
$1.12
130B
BOLT-FLANGED,8X30
130BA0830
$1.98
130C
BOLT-FLANGED,8X40
130BA0840
$1.98
130D
BOLT-FLANGED,10X16
130BA1016
$4.76
130E
BOLT-FLANGED,8X65
130CA0865
$2.32
