Kawasaki BRUTE FORCE® 750 Engine Cover(s) Diagram
#
Description
Price
11061
GASKET
11061-1119
$21.13
11065
CAP
11065-1151
$16.26
13272
PLATE
13272-1090
$3.65
14031
COVER-GENERATOR
14031-0127
$164.53
14069
BREATHER
14069-1051
$10.19
14091
COVER
14091-1365
$73.61
14091A
COVER,BELT CONVERTER
14091-1571
$21.80
16115
CAP-OIL FILLER
16115-0001
$14.18
39062
HOSE-COOLING,CARBURETOR-VALVE
39062-1382
$5.08
92005
FITTING
92005-1264
$7.56
92043
PIN,6.2X8X14
92043-1263
$0.43
92049
SEAL-OIL,12X22X5
92049-0783
$7.75
92055
RING-O,27.7X2.4
92055-091
$6.22
92055A
RING-O,25.7X2.4
92055-1136
$5.00
92055B
RING-O,20X2
92055-1146
$8.58
92055C
RING-O,44.7X2.4
92055-1279
$7.34
92055D
RING-O,99.5X2.0
92055-1632
$11.16
92055E
RING-O,20X3
92055-2185
$1.03
92066
PLUG,COVER
92066-0011
$15.94
92066A
PLUG,25X8
92066-0012
$11.70
92067
PLUG,30X8
92067-024
$11.29
92170
CLAMP
92170-1492
$5.00
92170A
CLAMP
92170-1493
$5.00
92172
SCREW,5X8
92172-0119
$2.12
132
BOLT-FLANGED-SMALL,6X12
132BA0612
$1.20
132A
BOLT-FLANGED-SMALL,6X20
132BA0620
$2.49
132B
BOLT-FLANGED-SMALL,6X30
132BA0630
$2.65
132C
BOLT-FLANGED-SMALL,6X55
132BA0655
$2.80
132D
BOLT-FLANGED-SMALL,6X65
132BA0665
$4.45
601
BEARING-BALL
601A6001
$11.71
670
O RING,18MM
670D2018
$1.91
