Description

Price

1

PANEL, INSTRUMENT

8Y1-77711-01-00

Unavailable

2

PANEL, INSTRUMENT

8R4-77712-00-00

Unavailable

3

BRACKET 2

80F-77722-00-00

Unavailable

4

RIVET, BLIND

90267-48117-00

Unavailable

5

INDICATOR 1

8K2-77741-01-00

Unavailable

6

INDICATOR 2

8K4-77742-00-00

Unavailable

7

INDICATOR 2

87A-77742-00-00

Unavailable

8

INDICATOR 3

87A-77743-00-00

$1.82

9

INDICATOR 1

87A-77741-00-00

$1.82

10

INDICATOR 5

87A-77745-00-00

$1.82

11

INDICATOR 4

87A-77744-00-00

$1.87

12

SCREW, PAN HEAD

90157-05M19-00

Unavailable

13

WASHER(3SX)

92907-05100-00

$8.49

14

WASHER, PLATE 8067717800

90201-05029-00

$8.49

15

GROMMET, INSTRUMENT PANEL

8R4-77740-00-00

Unavailable

16

GROMMET (8R4)

90480-53313-00

Unavailable

17

BRACKET 1

8U0-77721-00-00

Unavailable

18

SHIELD 1

80F-77731-00-00

Unavailable

19

SCREW, PAN

98517-06012-00

Unavailable

20

WASHER, SPRING

92907-06100-00

Unavailable

21

WASHER(6TA)

92907-06600-00

Unavailable

22

GROMMET 122154860000

90480-12012-00

Unavailable

23

PATCH 1

80F-2171F-00-00

Unavailable

24

LABEL, WARNING 2

8Y1-77762-00-00

Unavailable

25

BRACKET 1

80F-23881-00-00

Unavailable

26

SPACER

80F-23858-00-00

Unavailable

Yamaha BR250TU (BRAVO LT) 1994 INSTRUMENT PANEL Diagram

PANEL, INSTRUMENT

PANEL, INSTRUMENT

BRACKET 2

RIVET, BLIND

INDICATOR 1

INDICATOR 2

INDICATOR 2

INDICATOR 3

INDICATOR 1

INDICATOR 5

INDICATOR 4

SCREW, PAN HEAD

WASHER(3SX)

WASHER, PLATE 8067717800

GROMMET, INSTRUMENT PANEL

GROMMET (8R4)

BRACKET 1

SHIELD 1

SCREW, PAN

WASHER, SPRING

WASHER(6TA)

GROMMET 122154860000

PATCH 1

LABEL, WARNING 2

BRACKET 1

SPACER
