Kawasaki Bayou 300 4X4 (Canada Only) Front Fender(s) Diagram

Description

Price

130

BOLT-FLANGED,6X16

130C0616

Unavailable

130A

BOLT-FLANGED,6X18

130J0618

Unavailable

14024A

COVER,FRONT FENDER,RR,H.GREEN

14024-1657-6A

$43.18

14090A

COVER,FRONT FENDER,FR,H.GREEN

14090-1656-6A

$32.05

35004A

FENDER-FRONT,H.GREEN

35004-1381-6A

$227.63

35011

STAY,FRONT FENDER,UPP

35011-1420

$23.05

35011A

STAY,FR FENDER,LH,LWR FLAP

35011-1600

$29.19

35011B

STAY,FR FENDER,RH,LWR FLAP

35011-1601

$29.19

35019

FLAP,FR,BLACK

35019-1291-6Z

$16.25

35019A

FLAP,FR,SIDE,LH,BLACK

35019-1292-6Z

Unavailable

35019B

FLAP,FR,SIDE,RH,BLACK

35019-1293-6Z

$40.65

35019C

FLAP,FR,LWR,LH,BLACK

35019-1294-6Z

$73.21

35019D

FLAP,FR,LWR,RH,BLACK

35019-1295-6Z

$73.21

92009

SCREW,6X22,BLACK

92009-1256

$1.96

92009A

SCREW,6X16

92009-1621

Unavailable

92015

NUT,FLANGED,6MM,BLACK

92015-1233

$4.18

92015A

NUT,LOCK,FLANGED,6MM

92015-1675

$3.29

92015B

NUT,CLAMP,6MM

92015-1678

$4.18

92022

WASHER,6.5X16X1.0

92022-1093

$1.49

92027

COLLAR,FUEL TANK FITT

92027-1134

$7.83

92027A

COLLAR,L=4.7

92027-1964

$5.61

92072

BAND,L=149

92072-031

$3.81

92075

DAMPER,CASE

92075-222

$5.61

92143

COLLAR,L=9.6

92143-1016

$4.67

92172

SCREW,6X14

92172-0004

$1.98
