Honda ATC250RA (82) ALL TERRAIN CYCLE, JPN, VIN# JH3TB060-CC100001 TO JH3TB060-CC119528 FRONT WHEEL + FRONT BRAKE DISK 81-82 Diagram

#

Description
Price

1

RIM, RR. WHEEL (OUTER) *YR111MU* (GLAMIS GOLD METALLIC-U) (NOT AVAILABLE)

42712-950-010ZA

Unavailable

2

RIM, RR. WHEEL (INNER) *YR111MU* (GLAMIS GOLD METALLIC-U)

42713-950-010ZA

Unavailable

3

TIRE, WHEEL (22X11.0-8) (OHTSU) (NOT AVAILABLE)

42751-961-004

Unavailable

4

VALVE, RIM (SCHRADER) This part replaces 42753-634-003.

42753-SB8-661

$1.93

4

VALVE, RIM (SCHRADER) This part replaces 42753-634-006.

42753-SB8-661

$1.93

4

VALVE, RIM (SCHRADER) This part replaces 42753-634-007.

42753-SB8-661

$1.93

4

VALVE, RIM (SCHRADER) This part replaces 42753-671-003.

42753-SB8-661

$1.93

4

VALVE, RIM (SCHRADER) This part replaces 42753-937-000.

42753-SB8-661

$1.93

5

AXLE, FR. WHEEL (NOT AVAILABLE)

44301-961-000

Unavailable

6

COLLAR, FR. AXLE SIDE (NOT AVAILABLE)

44311-961-000

Unavailable

7

COLLAR, L. FR. AXLE SIDE

44312-961-000

Unavailable

9

HUB, FR. WHEEL *YR109MU* (SPARK GOLD METALLIC-U) (NOT AVAILABLE)

44610-961-010ZA

Unavailable

10

COLLAR, FR. AXLE CENTER (NOT AVAILABLE)

44621-961-000

Unavailable

11

PATCH, SUPPORT PLATE *YR111MU* (GLAMIS GOLD METALLIC-U) (NOT AVAILABLE)

44715-950-000ZA

Unavailable

12

DISK, FR. BRAKE

45121-961-010

Unavailable

13

BOLT, SPECIAL (8X18) (NOT AVAILABLE)

90002-961-000

Unavailable

14

BOLT, WHEEL

90101-942-000

Unavailable

15

BOLT, HUB (8X25)

90103-943-300

$8.11

16

NUT, AXLE (14MM)

90305-401-680

$11.65

17

WASHER, TONGUED (NOT AVAILABLE)

90481-961-000

Unavailable

18

DUST SEAL (23X42X7) (NOK) This part replaces 91251-958-003.

91251-958-004

$14.25

18

DUST SEAL (23X42X7) (NOK)

91251-958-004

$14.25

19

O-RING, WHEEL (160X4.2)

91351-958-670

$15.23

20

NUT, HEX. (8MM)

94001-08000-0S

$1.49

20

NUT, HEX. (8MM) This part replaces 94001-08080-0S.

94001-08000-0S

$1.49

20

NUT, HEX. (8MM) This part replaces 94001-08080-05.

94001-08000-0S

$1.49

20

NUT, HEX. (8MM) This part replaces 94001-08200-0S.

94001-08000-0S

$1.49

21

WASHER, SPRING (8MM)

94111-08800

$1.49

22

PIN, COTTER (3.0X45) This part replaces 94201-30250.

94201-30450

$1.49

22

PIN, COTTER (3.0X45) This part replaces 94201-30300.

94201-30450

$1.49

22

PIN, COTTER (3.0X45) This part replaces 94201-30400.

94201-30450

$1.49

22

PIN, SPLIT (3.0X45)

94201-30450

$1.49

23

BEARING, RADIAL BALL (6302)

96100-63020-10

Unavailable
