Honda ATC200XA (83) ALL TERRAIN CYCLE, JPN, VIN# JH3TB052-DC263800 TO JH3TB052-DC340134 KICK STARTER SPINDLE Diagram

#

Description
Price

1

O-RING (11.8X2.4) This part replaces 16997-357-003.

91302-ZE9-003

$2.57

1

O-RING (11.8X2.4) This part replaces 91302-ZE9-000.

91302-ZE9-003

$2.57

1

O-RING (11.8X2.4)

91302-ZE9-003

$2.57

1

O-RING (11.8X2.4) This part replaces 91320-HA5-000.

91302-ZE9-003

$2.57

1

O-RING (11.8X2.4) This part replaces 91320-HA5-003.

91302-ZE9-003

$2.57

1

O-RING (11.8X2.4)

91320-MJ6-003

$2.79

2

PINION, KICK STARTER | Use up to Engine SN 6000036 This part replaces 28211-965-000.

28211-965-010

Unavailable

2

PINION, KICK STARTER | Use up to Engine SN 6000036

28211-965-010

Unavailable

2

PINION, KICK STARTER

28211-965-010

Unavailable

3

GEAR, STARTER DRIVEN (NOT AVAILABLE)

28215-965-000

Unavailable

3

GEAR, STARTER DRIVEN (NOT AVAILABLE) | Use from Engine SN 6019047 This part replaces 28215-965-010.

28215-965-000

Unavailable

4

GEAR, STARTER DRIVE

28216-965-000

Unavailable

4

GEAR, STARTER DRIVE | Use from Engine SN 6019047

28216-965-000

Unavailable

4

GEAR, STARTER DRIVE | Use from Engine SN 6019047 This part replaces 28216-965-010.

28216-965-000

Unavailable

5

RATCHET, KICK STARTER

28221-437-000

$64.70

6

SPINDLE, KICK STARTER (NOT AVAILABLE) This part replaces 28251-965-000.

28251-965-010

Unavailable

7

SPRING, KICK STARTER RATCHET (NOT AVAILABLE) This part replaces 28253-965-000.

28253-965-010

Unavailable

7

SPRING, KICK STARTER RATCHET (NOT AVAILABLE)

28253-965-010

Unavailable

8

SEAT, RATCHET SPRING

28254-437-000

Unavailable

9

SHAFT, KICK STARTER (NOT AVAILABLE)

28255-965-000

Unavailable

10

SPRING, KICK STARTER | Use up to Engine SN 6011090 This part replaces 28261-965-000.

28261-965-010

Unavailable

10

SPRING, KICK STARTER | Use up to Engine SN 6011090

28261-965-010

Unavailable

10

SPRING, KICK STARTER

28261-965-010

Unavailable

11

COLLAR, KICK SPINDLE

28262-437-000

$14.16

12

RETAINER, STARTER SPRING

28263-437-000

Unavailable

13

BOLT, KICK RATCHET

90004-437-000

$8.18

14

WASHER A, THRUST (20MM)

90453-107-000

$2.25

15

WASHER, THRUST (18X32)

90456-KA4-000

$4.76

16

WASHER, THRUST (22MM)

90456-323-000

Unavailable

17

WASHER, THRUST (12MM)

90459-107-000

$1.49

18

OIL SEAL (22X31X5) (ARAI)

91205-965-003

$5.80

19

CIRCLIP (OUTER) (16MM)

94510-16000

$1.49

20

CIRCLIP (OUTER) (20MM)

94510-20000

$1.49
