Suzuki AN650 (2009) SIDE COVER (AN650K8) Diagram

#

Description
Price

1

COVER, SIDE RH (BLACK)

47111-10G20-YAY

$422.05

1

COVER, SIDE RH (GOLD) | MODEL K8

47111-10G20-YLC

Unavailable

1

COVER,SIDE,R | MODEL K9 This part replaces 47111-10G20-YPA.

47111-10G21-YPA

$312.57

2

COVER, SIDE LH (BLACK)

47211-10G31-YAY

Unavailable

2

COVER, SIDE LH (GOLD) | MODEL K8

47211-10G31-YLC

Unavailable

2

COVER,SIDE,L | MODEL K9 This part replaces 47211-10G31-YPA.

47211-10G32-YPA

$327.05

3

EMBLEM, SIDE COVER

68131-10G10

$61.93

4

EMBLEM, "650"

68131-10GA0

$28.27

5

CLIP (BLACK)

09409-06314-5PK

$2.78

6

CLIP (BLACK)

09409-08308-5ES

$1.97

7

LID, FUEL (BLACK)

47381-10G11-YAY

$43.88

7

LID, FUEL (GOLD) | MODEL K8

47381-10G11-YLC

Unavailable

7

LID, FUEL (WHITE) | MODEL K9

47381-10G11-YPA

$45.37

8

HINGE

47382-10G10

$8.65

9

SCREW

03541-0512B

$1.78

10

SPRING, LID

47388-10G01

$5.11

11

COVER, FRAME CENTER (BLACK)

47311-10G01-YAY

$96.33

11

COVER, FRAME CENTER (GOLD) | MODEL K8

47311-10G01-YLC

Unavailable

11

COVER, FRAME CENTER (WHITE) | MODEL K9

47311-10G01-YPA

Unavailable

12

.EMBLEM,"SUZUKI" (SILVER) | FOR YAY,YLC This part replaces 68271-34A00-YES.

68271-34A01-YES

$6.85

12

EMBLEM,"SUZUKI" | FOR YPA This part replaces 68271-34A00-YJH.

68271-34A01-YJH

$8.35

13

CLIP (BLACK)

09409-08308-5ES

$1.97

14

COVER, FRAME LOWER (BLACK)

47321-10G00-YAY

$134.47

14

COVER,FRAME LWR | MODEL K8 This part replaces 47321-10G00-YLC.

47321-10G00

$100.03

14

COVER, FRAME LOWER (WHITE) | MODEL K9

47321-10G00-YPA

$112.17

15

CUSHION This part replaces 09320-04008.

09320-04012

$2.91

16

CUSHION, FRAME COVER

47115-10G00

$4.27
