Suzuki AN650 (2009) REAR WHEEL (AN650K8/K9) Diagram

#

Description
Price

1

WHEEL, REAR (14M/CXMT4.50) (SILVER)

64111-10G10-YD8

$1,063.85

2

SPACER, REAR HUB BEARING

64731-10G00

$46.25

3

BEARING This part replaces 08123-62047.

08123-6204B

$15.93

4

SEAL,OIL (27X47X7) This part replaces 09285-28001.

09285-28004

$11.27

5

BUSH, REAR HUB

09319-12062

$17.38

6

AXLE, REAR

64711-10G00

Unavailable

7

SPACER, RR AXLE RH

64741-10F00

$19.54

8

SPACER, REAR AXLE RH NO.1

64751-10G10

$17.78

9

SPACER, REAR AXLE LH

64772-10G00

Unavailable

10

WASHER

08322-0118B

$2.95

11

NUT

08319-3118A

$26.62

12

DISC, REAR BRAKE

69211-10G10

$315.58

13

BOLT, DISC

09106-08160

$3.22

14

JOINT ASSY, REAR HUB DRIVEN

64680-10G20

Unavailable

15

O RING, DRIVEN JOINT

09280-65003

$4.03

16

WASHER, JOINT

09169-06030

$3.42

17

WASHER, THRUST

64677-10G00

Unavailable

18

BOLT, DRIVEN JOINT WASHER

09119-06049

$1.63

19

TIRE, REAR, 160/60R14M/C 65H (BRIDGESTONE) | TH01 R RADIAL MODEL K8

65110-10G00

$371.58

19

TIRE,RR(160/60R | TH01 R RADIAL MODEL K9 This part replaces 65110-10G10.

65110-10G11

$313.43

20

VALVE ASSY, WHEEL RIM (TR412)

43130-10G00

$66.18

21

BALANCER, WHEEL (10G)

43222-73H10

$6.57

21

BALANCER, WHEEL (20G)

43224-73H10

$4.02

21

BALANCER, WHEEL (30G)

43226-73H10

$4.69
