Suzuki AN400AK9 (2009) MAGNETO (MODEL K8/K9) Diagram

#

Description

Price

1

NUT, MAGNETO ROTOR

31792-18A00

$11.87

2

STATOR ASSY This part replaces 32101-15G20.

32101-15G61

$621.33

3

ROTOR ASSY, MAGNETO

32102-15G30

Unavailable

4

CLAMP, MAGNETO LEAD

32371-32E00

$6.30

5

BOLT

07130-0512B

$2.50

6

BOLT

07130-0630B

$3.37

7

KEY

09420-04008

$3.42
