Suzuki AN400AK9 (2009) FRONT WHEEL (AN400AK9) Diagram

#

Description
Price

1

WHEEL, FRONT (14M/CXMT3.00) (SILVER)

54111-05H10-YD8

Unavailable

2

SPACER, FRONT WHEEL BEARING

09180-15070

$20.13

3

BEARING, FRONT WHEEL

08123-62027

$18.57

4

SEAL,OIL This part replaces 09285-22005.

09285-22007

$7.05

5

RING, SPEED SENSOR FR (50T)

54162-27G00

$140.15

6

BOLT, SPEED SENSOR

07130-05127

$3.15

7

AXLE,FRONT

54711-05H00

Unavailable

8

SPACER, FRONT AXLE, L

54751-14F00

$21.35

9

DISC, FRONT BRAKE

59221-14G20

Unavailable

10

BOLT, FRONT BRAKE DISC

09106-08160

$3.57

11

TIRE, FRONT

55110-05H00

Unavailable

12

VALVE ASSY, WHEEL RIM

43130-24A00

$8.85

13

BALANCER, WHEEL NO.1

43222-73H10

$5.82

13

BALANCER, WHEEL NO.2

43224-73H10

$5.50

13

BALANCER, WHEEL NO.3

43226-73H10

$6.42
