Suzuki AN400 (2006) SEAT SUPPORT BRACKET Diagram

#

Description
Price

1

BRACKET, SEAT HINGE | %CK43A42100792 This part replaces 45240-14G10.

45240-14G20

Unavailable

1

BRACKET, SEAT HINGE | CK43A42100793%

45240-14G20

Unavailable

2

NUT This part replaces 08316-10063.

08316-1006B

$2.50

3

CABLE,SEAT LOCK | MODEL K3 This part replaces 45280-14G01.

45280-14G10

$50.37

3

CABLE,SEAT LOCK | MODEL K4 This part replaces 45280-14G21.

45280-14G32

$54.32

3

CABLE,SEAT LOCK | MODEL K5/K6 This part replaces 45280-14G30.

45280-14G32

$54.32

4

GUIDE, SEAT LOCK CABLE This part replaces 45288-10G00.

45288-10G01

Unavailable

5

BOLT (6X18.5) | %CK43A42100792

09111-06068

$6.13

5

BOLT (6X25) | CK43A42100793%

09103-06211

$3.33

6

LOCK ASSY,SEAT | MODEL K3 This part replaces 45700-14FA0.

45700-14FA2

$78.80

6

LOCK ASSY,SEAT | MODEL K4 This part replaces 45700-14FC0.

45700-14FC2

$78.80

6

LOCK ASSY,SEAT | MODEL K5/K6 This part replaces 45700-14FC1.

45700-14FC2

$78.80

7

BOLT This part replaces 07130-06123.

07130-0612A

$2.50

8

CUSHION (10X28X19)

09320-10045

$3.76

9

SPACER (6.5X10X9.4)

09180-06286

$2.50

10

SCREW (6X20)

09136-06105

$1.97

11

BOLT This part replaces 01547-05103.

01547-0510B

$2.97

12

CLAMP | MODEL K4/K5

09407-14403

$2.26

12

CLAMP | MODEL K6

09407-14403

$2.26

13

SPACER, SEAT HINGE BRACKET | CK43A42100793%

45231-14G00

$10.95

14

CLAMP | MODEL K6

09407-18402

$2.19
