Kawasaki A1-B OPTIONAL PARTS Diagram
#
Description
Price
1
GRIP KNEE L.H
51061-015
Unavailable
2
GRIP KNEE R.H
51062-013
Unavailable
3
GASKET-LIQUID,TB1105B,SILVER
92104-002
Unavailable
5~15
UNAVAILABLE IN PRICE BOOK
23004-017
Unavailable
5
RIM HEAD LAMP
23006-022
Unavailable
6
UNAVAILABLE IN PRICE BOOK
23007-019
Unavailable
7
BULB 12V 35/35W
92069-045
$5.66
8
SOCKET HEAD LAMP
23008-017
$16.48
9
CLAMP HEAD LAMP LENS
23009-012
$6.52
10
SCREW-CSK-RD-CROS
222E0510
$3.16
10
UNAVAILABLE IN PRICE BOOK
22E0510A
Unavailable
11
UNAVAILABLE IN PRICE BOOK
23008-018
Unavailable
12
BULB 12V 4W
92069-046
$1.88
13
SCREW PAN HEAD 3X6
211B0306
$0.24
13
SCREW-PAN-CROS,3X6
220B0306
$0.63
14
WASHER SPRING 3MM
461F0300
$0.46
15
NUT-HEX
311B0300
$0.40
15
NUT-HEX
311B0300
$0.40
16
GROMMET 13MM
850A1301
$1.17
17
BOLT,HEX HEAD,10X25
92007-045
$10.62
18
WASHER SPRING 10MM
461F1000
$0.67
19
BODY HEAD LAMP C.RED
23005-017-24
$105.93
19
BODY HEAD LAMP C.BLUE
23005-017-27
$42.31
20
BODY-HEAD LAMP,F BLK
23005-018-21
Unavailable
21
LAMP ASSY HIGH BEAM
23016-002
Unavailable
22
BULB 12V 1.5W
92069-017
$4.92
23
RIM HEAD LAMP
23006-013
$26.23
24
CAP FUEL TANK LOCKING
51049-009
$56.30
