KTM 990 SUPER DUKE BLACK 2011 REAR WHEEL Diagram

#

Description

Price

1

REAR WHEEL CPL. BLACK 11

6101000114430

Unavailable

2

Grooved ball bear. 6205-2RSHC3

0625062052

Unavailable

3

BEARING SPACER TUBE REAR 05

61010011000

Unavailable

4

CIRCLIP DIN0472-52X2

0472052200

Unavailable

5

Radial shaft seal 30X52X7

0760305271

Unavailable

6

SPACER BUSH. REAR WHEEL R/S 03

60010013000

Unavailable

11

SPROCKET SUPPORT CPL. BLACK

6901005004430

Unavailable

12

SPACER CHAIN WHEEL SUPPORT

69010012000

Unavailable

13

BALL BEARING 6006 DDU2CG23S6NM

0625060060

Unavailable

14

BEAR.DIST. RING 30,3X37,8X4,65

69010054000

Unavailable

16

DAMPING RUBBER 05

61010059000

Unavailable

17

REAR SPROCKET 38-T STEEL 05

61010051138

Unavailable

17

REAR SPROCKET 39-T STEEL 05

61010051139

Unavailable

17

REAR SPROCKET 40-T STEEL 05

61010051140

Unavailable

18

BOLT FOR SPROCKET SUPPORT 05

61010056000

Unavailable

19

NUT REAR SPROCKET 05

61010057000

Unavailable

20

BRAKE DISK REAR D=240MM 05

61010060000

Unavailable

21

SPECIAL SCREW M8X18 05

61009062018

Unavailable

22

WHEEL SPINDLE REAR CPL.

60010081144

Unavailable

23

Chain tension adjuster, right,

60010084000

Unavailable

24

Collar nut M25X1.5 WS=32 05

61010086000

Unavailable

25

screw M10x1.25x50 WS10

50304040100

Unavailable

26

HH COLLAR NUT M10X1,25 WS=13

58414030000

Unavailable

27

CHAIN 525 INCL. MASTER LINK

60010365118

Unavailable

28

MASTER LINK FOR CHAIN 525 07

60010266000

Unavailable

29

STICKER MARCH. 2L/S+2R/S WHITE

00050000120

Unavailable

31

VALVE CPL. BREMBO DUKE 2003

58709076000

Unavailable

98

DRIVETRAIN KIT SD/SD-R 16T/38T

00050002021

Unavailable

99

REAR WHEEL REP. KIT

61010015000

Unavailable
