KTM 690 DUKE WHITE CUP 2012 CONVERSION KIT Diagram

#

Description

Price

1

FOOTREST CARRIER FRONT R/S

7600303900001S

Unavailable

1

COUNTER-SUNK SCREW ISA45 M8X30

0019080306S

$1.49

1

SHIFT LEVER

76034036000

$60.77

1

Pull rod tube

76003170000

Unavailable

1

FOOT BRAKE LEVER CPL.

7601305004401S

Unavailable

1

Brake lover pedal Duke 94

58303060051

$15.04

1

HH collar screw M6x20 TX30

0025060206

$3.08

1

HOSE FOR RESERVOIR 6X1,5

69013069001

Unavailable

1

Cap head bold ISO 14580 M6x16

014580060166

$2.05

1

MANIFOLD EVO

76005907100

Unavailable

1

collar bushing 8.5x12x23.5x10

58405050065

$5.23

1

CHAIN FAIL. PROTECTION

7600456500049

Unavailable

1

MONOSHOCK 690 DUKE-R 2012

15187L1101

Unavailable

1

BRAKE CALIPER BL. WITHOUT PADS

7501308010130

Unavailable

1

BRAKE CALIPER SUPPORT REAR 08

7501307500030

$98.55

1

BRAKE HOSE REAR 2007

75013072000

Unavailable

1

AH SCREW DIN0912-M 6X35

0912060353

$2.05

1

Grooved ball bearing 608 2RS C

0625006087

$21.40

1

SPECIAL SCREW M6X19 WS=8 10.9

59009062019

$2.05

1

RET.PANEL FLUID RES. FRONT 02

57313001050

$19.35

1

HH collar screw M6x10 TX30

0025060106

$3.08

1

PLASTIC CAP SFL10

54403135000

$2.05

1

AIR FILTER BOX CUP EDITION

76006501033

Unavailable

1

SILENCER CARRIER CPL.

76005984044

Unavailable

1

COVER REAR LIGHT

7600858000049

Unavailable

1

SPECIAL SCREW M6X21 WS=8

60035001000

$3.08

1

FORK WP 690 DUKE-R

05187L1101

Unavailable

1

HANDLEBAR D=28 MM SX/EXC OR.

5480200130004

Unavailable

1

HANDLEBAR D=22MM 658-SILVER

76002501000

Unavailable

1

HANDLEBAR SUPPORT 22MM 2T 2000

59001039000

$53.05

1

HANDLEBAR CLAMP D=22MM 2001

50301038000

$21.50

1

CALIPER L/S BLACK-WITHOUT PADS

6251301510130

$295.77

1

BRAKE PIPE FRONT CPL. 08

75613112000

$111.19

1

HAND BRAKE CYLINDER 2011

75613001100

Unavailable

1

BRAKE FLUID RESERVOIR CPL.

61013009102

$41.51

1

SCREW + NUT FOR RESERVOIR

61013009103

$17.10

1

SCREW RET.PANEL-RESERVOIR

61013013050

$9.06

1

RUBBER BUSH 05

61013013000

$3.08

1

RET.PANEL FLUID RES. FRONT 05

61013009001

$9.34

1

NUT FOR RESERVOIR

61013009004

$3.08

1

YDNAC-clamp 10101 (10.4MM)

58007017000

$3.08

1

SPACER BUSHING 10,1X20X7,5 07

6111302200033

Unavailable

1

SILENCER TITAN

76005979000

Unavailable

1

NUMBER PLATE

7600850100028A

Unavailable

1

COVERFOIL SPEEDOMETER/FLASHER

76014069090

Unavailable

1

SEAT ERGO DRIVER

76007940000

Unavailable

1

PASSENGER SEAT COVER CPL.

76007940044

Unavailable

1

FRONT SPOILER WHITE

7600852000028A

Unavailable

1

REAR BRACKET FOR FRONT SPOILER

76008521000

Unavailable

1

FRONT BRACKETL/SFRONTSPOILER

76008522000

Unavailable

1

FRONT BRACKETR/SFRONTSPOILER

76008523000

Unavailable

1

FOOTREST BLOCK

76003544000

Unavailable

1

FOOTREST FRONT

76003540100

Unavailable

1

CRASH BAR SET KPL. ORANGE

7601296804404

Unavailable

1

SIDESTAND DISASSEMBLY KIT

61011046044

Unavailable

1

REAR SPROCKET ORANGE 38-T

5841005103804

$101.14

1

Engine sprocket 15-t, damped

58033029115

$30.75

1

HANDGUARD BRACKET

76002579044

Unavailable

1

SHIFTING LEVER CPL.

7603403104401S

Unavailable

1

STEP PLATE SHIFTING LEVER

69034032000

$12.15

1

RUBBER FOR SHIFT LEVER 05

61034035000

$6.91

1

BUSHING

76034039000

$10.00

1

FOOTREST CARRIER FRONT L/S

7600303800001S

Unavailable

1

CAMSHAFT CPL. 07

76236010044

Unavailable

1

BRAKE DISC FRONT D=320X5

6900906000030

$424.86

1

SHIFTING LEVER CPL.

76034531044

Unavailable
