KTM 640 ADVENTURE-R D <1998> LIGHTING SYSTEM Diagram

#

Description
Price

0

FLASHER REAR L/S / FRONT R/S

58311112000

Unavailable

1

HEADLIGHT LOW BEAM DUKE'94

58311010000

Unavailable

2

BULB H1 12V 55W WHITE

58311038000

Unavailable

3

SPECIAL NUT M5X25 WS=10

58311044000

Unavailable

4

washer DIN 125 A -8.4

0125080003

Unavailable

5

rubber grommet D=8mm open

31008060000

Unavailable

6

TOOTH LOCK WASH. DIN6797-J 5,3

0797050003

Unavailable

7

HH SCREW DIN0933-M 5X12

0933050123

Unavailable

8

ADJUSTING SCREW M5X30 CPL.

58311011000

Unavailable

9

SPRING L=16MM

12003007052

Unavailable

10

COLLAR BUSHING 5 X 10 X 6 ALU

54603073000

Unavailable

20

HEADLIGHT HIGHBEAM DUKE '94

58311110000

Unavailable

21

BULB SOCKET BA9S

58311039000

Unavailable

22

BULB 12V 2W BA9S

44111005100

Unavailable

23

CLUTCH LEVER BOOT '95

58302126000

Unavailable

25

rubber grommet D=8mm open

31008060000

Unavailable

26

SPACER BUSHING 6,5 X 8 X 7

58011039000

Unavailable

30

FLASHER FRONT L/S / REAR R/S

58311012000

Unavailable

31

FLASHER LENS L/S AND R/S

58311013000

Unavailable

32

BULB 12V 10W (BA15S)

44111015100

Unavailable

33

washer DIN 125 A 10.5

0125100003

Unavailable

34

LOCK WASHER DIN6797-J10,5 ZI

0797100003

Unavailable

35

HEXAGON NUT DIN0934-M10X1,25

0934102003

Unavailable

40

REAR LIGHT CPL. CEV 358 '93

58311040000

Unavailable

41

LENS '93

58311041000

Unavailable

42

BULB 12V 21/5W (BAY15D)

57011045000

Unavailable

45

Self lock. nut DIN985-M6-A2

0985060003

Unavailable

46

Washer DIN9021-A 6.4

0021060003

Unavailable
