Polaris 600 XCR - 0961676 CYLINDER 600 XCR 0961676 and EUROPEAN 600 XCR E961676 (4932123212C008) Diagram

#

Description
Price

1

COVER,HEAD,(3 CYL) (Incl. 2)

3085190

Unavailable

2

PIPE, WATER, CPL.

3084431

Unavailable

3

PIN, DOWEL

3084721

$4.79

3

PIN, DOWEL

3084721

$4.79

3

PIN, DOWEL

3084721

$4.79

4

O-RING, (HEADCOVER) (Head Cover)

3084434

Unavailable

5

HEAD, CYL.,(MAG) (Mag)

3084674

Unavailable

6

NUT(10)

3080285

Unavailable

7

WASHER LOCK ,(10)

3080530

$3.19

8

GASKET,EXHAUST,NA(10) Substituted by 3086757

3084439

Unavailable

9

STUD Substituted by 3085326

3084270

Unavailable

10

NUT-FLANGE(10)

3082911

$1.99

11

GASKET, CYLINDER (Cylinder)

3084593

Unavailable

12

O-RING Substituted by 3085619

3084272

Unavailable

13

ADAPTER, CARB. (Incl. 12)

3084673

Unavailable

14

Bolt, Allen

3081330

$3.99

15

SCREW,(10)

3081497

$2.39

16

BAND ASM. (Incl. 15)

3083166

$19.84

17

GASKET #1,HEAD Substituted by 3085613 (Std.)

3085003

Unavailable

18

VALVE, CHECK Substituted by 3086785

3083337

Unavailable

19

PLUG

3084428

$3.51

20

CYLINDER (Incl. 9, 19)

3085049

$734.99

21

GASKET,HEAD (Opt.)

3085005

Unavailable

22

HEAD, CYL.,(CEN) (Cen)

3084675

Unavailable

23

HEAD, CYL.,(PTO) (PTO)

3084676

Unavailable

24

O RING

3085192

Unavailable

25

SPACER

3084722

Unavailable

26

SWITCH,THERMAL,IOS

3084284

Unavailable

27

BOLT, FLANGE ,(10)

3084435

Unavailable

28

Bolt, Flange

3084437

Unavailable
