Polaris 600 INDY CROSSCOUNTRY 136 (R01) - S23TDL6KSA ENGINE, AIR INTAKE SYSTEM - S23TDL6KSA (C601625) Diagram

#

Description
Price

1

SCREEN-INTAKE RH

5814971

$27.99

2

SCREW-#10X3/4-HI/LO-PN-T25,TRX-M

7512026

$1.49

2

SCREW-#10X3/4-HI/LO-PN-T25,TRX-M

7512026

$1.49

2

SCREW-#10X3/4-HI/LO-PN-T25,TRX-M

7512026

$1.49

2

SCREW-#10X3/4-HI/LO-PN-T25,TRX-M

7512026

$1.49

3

VENT-INTAKE RH

5456411

$32.37

4

MOUNT-INTAKE RH

5458757

$13.75

5

ASM-INTAKE

1206200

$145.22

6

MOUNT-INTAKE LH

5458756

$13.75

7

VENT-INTAKE LH

5456410

$32.37

8

SCREEN-INTAKE LH

5814970

$27.99

9

SCR-M6X1.0X25-HX/FL-Y/D

7516823

$3.19

10

CLIP-"U",M6.0X1.0

7547366

$5.99

11

SCR-TX TRUSS-#14X3/4, HI/LO ZBK

7519045

$3.19

12

ASM-AIR SILENCER

1208717

$121.02

13

FOAM, INTAKE, LOWER

5813962

$12.94

14

FOAM-SEAL,REAR COOLER

5810947

$4.03

15

CLAMP-NARROW BAND(1.77/2.75)

7080909

$7.99

16

Clip, Dart, Nylon

7670067

$3.99

17

PLUG-DRAIN

5414472

$5.59

18

ASM-TUBE INTAKE [INCL. 17]

1206198

$116.17

19

RIVET-TUFLOK,.315-.325X.787

7661855

$1.49
