Partiron

Polaris 600 INDY CROSSCNTRY 136 (R01) - S22TDL6KSA SUSPENSION, SHOCK, FRONT TRACK - S22TDL6KSA ALL OPTIONS (601618) Diagram

#

Description
Price

-

SHOCK-F/T W/E 2" C/A HI/LO [INCL. 1-27]

7045849

$924.99

1

LOOP-SHAFT, BLU ANO

1801088

$129.51

2

SHAFT, FT, SS

1800774

$150.06

3

SCRAPER, ICE, SHAFT

1800776

$28.32

4

RETAINER-SPRING CLIP, ANO BLUE

1800925

$39.99

5

BODY, RESERVOIR, 3.5L, BLK

1801080

$154.90

6

BUSHING

1800406

$5.65

7

SLEEVE, 1.685"L

1800039

$15.99

8

SLEEVE- 1.150L

1800405

$28.32

9

BUMP STOP, 1.58x.73

1800649

$43.56

10

BUSHING, URETHANE

1800033

$19.99

11

ASM-SEAL HEAD 2.0

1801083

$141.65

12

ASM-PISTON, IFP 1.750

1801186

$64.99

13

O-RING BODY LOOP

1800030

$2.02

13

O-RING BODY LOOP

1800030

$2.02

14

O-RING, 2-324

1800184

$5.65

15

BODY, FT SHOCK, BLK

1800775

$164.99

16

ADJUSTER-HS-LS W/KNOB

1801059

$459.99

16

ADJUSTER-HS-LS W/KNOB

1801059

$459.99

17

END CAP, RESERVOIR, 2"

1801006

$114.99

18

RETAINING RING WIRE 0.0625 X 1.750ID

1800795

$7.27

19

NUT-FLEX-TOP LOCK 7/16

1801000

$7.99

20

PISTON ASSEMBLY

-------

Unavailable

21

WER STICKER

-------

Unavailable

22

LOOP-BODY 2.0 PB 70 DEG [NOT AVAILABLE]

1801091

$595.46

23

O-RING, 2-134

1800502

$1.99

24

SPRING ADJUSTER, BLUE

1801162

$82.29

25

WEAR BAND, SPRING

1800780

$64.99

26

NUT, JAMB, 2"

1800704

$22.21

27

WASHER-METAL SEALING

1801005

$13.75

27

WASHER-METAL SEALING

1801005

$13.75

28

SPRING-COMP 135/185#8 2" MBLK

7045856-458

$89.99

29

SHIELD-SHOCK, W/E 2"

5452873

$28.32
