Polaris 600 INDY CROSSCNTRY 136 (R01) - S22TDL6KSA SUSPENSION, CONTROL ARMS and SPINDLE - S22TDL6KSA (C601613) Diagram

#

Description
Price

1

NUT- M8X1.25, FLG, NYLOC-OLIVE D

7547332

$3.99

1

NUT- M8X1.25, FLG, NYLOC-OLIVE D

7547332

$3.99

1

NUT- M8X1.25, FLG, NYLOC-OLIVE D

7547332

$3.99

1

NUT- M8X1.25, FLG, NYLOC-OLIVE D

7547332

$3.99

2

SHAFT-PIVOT GROOVED

5140556

$34.99

2

SHAFT-PIVOT GROOVED

5140556

$34.99

2

SHAFT-PIVOT GROOVED

5140556

$34.99

3

BUSHING-PIVOT

5450297

$3.19

3

BUSHING-PIVOT

5450297

$3.19

3

BUSHING-PIVOT

5450297

$3.19

3

BUSHING-PIVOT

5450297

$3.19

4

WSHR-18.2X25.X1.6 THICK ZOD

7556758

$3.19

4

WSHR-18.2X25.X1.6 THICK ZOD

7556758

$3.19

4

WSHR-18.2X25.X1.6 THICK ZOD

7556758

$3.19

4

WSHR-18.2X25.X1.6 THICK ZOD

7556758

$3.19

5

KIT, UPPER CONTROL ARM, LH, MOLY, INDY RED [INCLUDES 2-4 & 6-7]

2205673-293

$224.99

5

KIT, UPPER CONTROL ARM, RH, MOLY, INDY RED [INCLUDES 2-4 & 6-7]

2205674-293

$224.99

6

RING-RET INT 1.125"

7710642

$2.39

7

BEARING-SPHERICAL UCA 31MM

7061179

$33.32

8

WASHER-M12X25X1.6 THRU HARD ZOD

7556994

$3.19

8

WASHER-M12X25X1.6 THRU HARD ZOD

7556994

$3.19

9

ASM-SPINDLE LH BLK

1824939-067

$314.99

9

ASM-SPINDLE RH BLK

1824940-067

$314.99

10

NUT-HEX-M12X1.5 8 ZOD NYL

7547464

$3.19

11

BUSHING

5136910

$7.99

12

BUSHING-SKI PIVOT

5438460

$15.99

12

BUSHING-SKI PIVOT

5438460

$15.99

13

NUT-M10X1.5 HFN NYLOC ZOD

7547423

$3.99

13

NUT-M10X1.5 HFN NYLOC ZOD

7547423

$3.99

13

NUT-M10X1.5 HFN NYLOC ZOD

7547423

$3.99

13

NUT-M10X1.5 HFN NYLOC ZOD

7547423

$3.99

14

WSHR-FL .406X.812X.065-Y

7555806

$1.49

14

WSHR-FL .406X.812X.065-Y

7555806

$1.49

15

KIT-BEARING SPHERICAL LWR 10MM

2204229

$31.99

16

RING, RETAINING

7710539

$2.39

17

SCR-M10X1.5X75 10.9 HCS ZOD

7519015

$5.59

18

KIT, LOWER CONTROL ARM, LH, INDY RED [INCLUDES 2-4, 15, 16 & 22]

2205671-293

$299.99

18

KIT, LOWER CONTROL ARM, RH, INDY RED [INCLUDES 2-4, 15, 16 & 22]

2205672-293

$299.99

19

SCR-M10X1.5X60-8.8 HFS ZOD

7518941

$3.99

20

BUSHING-REDUCER,.500X.398,ZYW

5137876

$7.19

20

BUSHING-REDUCER,.500X.398,ZYW

5137876

$7.19

20

BUSHING-REDUCER,.500X.398,ZYW

5137876

$7.19

20

BUSHING-REDUCER,.500X.398,ZYW

5137876

$7.19

21

SCR-M10X1.5X50 8.8 HX/FL ZOD

7518971

$6.39

22

SHAFT-PIVOT LCA FRT GROOVED

5140557

$34.99

23

SCR-M10X1.5X95 HX FLG 10.9 ZOD

7518917

$4.79

24

O-RING,0.600IDX.210

5412290

$2.02

24

O-RING,0.600IDX.210

5412290

$2.02
