Sea-doo 3D RFI, 2004 Kart Seat Diagram

#

Description
Price

1

Kart Seat Kit | Includes 1 To 66

269001166

Unavailable

2

Kart Seat Ass'y | Includes 2 To 31

269001205

Unavailable

3

Not Available As Spare Part - Friction Washer

Unavailable

4

WARNING LABEL, KART SEAT - Call your local BRP dealership

219902454

Unavailable

5

Seat Trim

269001215

Unavailable

6

KART SEAT PLATE - Call your local BRP dealership

269001167

Unavailable

7

Socket Head Screw M6 X 25

205062560

$1.69

8

Flat Washer M6, Stainless

234062600

$0.77

9

Hex. Elastic Stop Nut M6

232561600

$1.15

10

Not Available As Spare Part - Friction Washer

Unavailable

11

Not Available As Spare Part - Friction Washer

Unavailable

12

Not Available As Spare Part - Friction Washer

Unavailable

13

Not Available As Spare Part - Friction Washer

Unavailable

14

Black, Dart

293730011

$0.99

15

Kart Seat Cover

269001147

Unavailable

16

Seat Ring

269001178

Unavailable

17

Black, Dart

293730006

$0.99

18

RH Seat Corner

269001157

Unavailable

19

LH Seat Corner

269001158

Unavailable

20

Rubber Stopper

708000758

$12.99

21

PINE SUPPORT - Call your local BRP dealership

269001150

Unavailable

22

Socket Head Screw M6 X 25

205062560

$1.69

23

Flat Washer M6, Stainless

234062600

$0.77

24

Hex. Elastic Stop Nut M6

232561600

$1.15

25

PINE - Call your local BRP dealership

269001149

Unavailable

26

PINE HANDLE - Call your local BRP dealership

269001152

Unavailable

27

PINE SPRING - Call your local BRP dealership

269001151

Unavailable

28

Hex. Elastic Stop Nut M6

232561600

$1.15

29

Stainless Flat Washer M6

234061600

$0.33

30

Flat Washer 10 mm, Stainless

234001600

$1.15

31

Not Available As Spare Part - Friction Washer

Unavailable

32

LATCH BASE - Call your local BRP dealership

269001156

Unavailable

33

LATCH COVER - Call your local BRP dealership

204070036

Unavailable

34

Latch Spring

269700017

$9.19

35

Hex. Screw M6 X 40

207064060

$1.69

36

BLACK SNAP CAP - Call your local BRP dealership

414436900

Unavailable

37

Stainless Flat Washer M6

234061600

$0.33

38

Hex. Elastic Stop Nut M6

232561600

$1.15

39

Flat Washer M6, Stainless

234062600

$0.77

40

SEAT HOOK - Call your local BRP dealership

291002036

Unavailable

41

Hex. Screw M6 X 35

207063560

$2.22

42

BLACK SNAP CAP - Call your local BRP dealership

414436900

Unavailable

43

Stainless Flat Washer M6

234061600

$0.33

44

Hex. Elastic Stop Nut M6

232561600

$1.15

45

Not Available As Spare Part - Friction Washer

Unavailable

45

Not Available As Spare Part - Friction Washer

Unavailable

46

Upper Foot Peg RH

291002042

Unavailable

46

Upper Foot Peg LH

291002043

Unavailable

47

Foot Peg Foam RH

291002123

Unavailable

47

Foot Peg Foam LH

291002122

Unavailable

48

Black, Dart

293730006

$0.99

49

Elastic Rope 4.3 mm

293850084

Unavailable

50

Upper Carpet RH

291002126

Unavailable

50

Upper Carpet LH

291002125

Unavailable

51

Lower Carpet RH

291002128

Unavailable

51

Lower Carpet LH

291002127

Unavailable

52

RH Foot Peg Holder

291002132

Unavailable

52

LH FOOT PEG HOLDER - Call your local BRP dealership

291002131

Unavailable

53

Bumper Plug, Black

291001040

$7.39

54

Plastite Torx Screw #10 X 7/8"

250000207

$2.00

55

Was 293200062 Seal

219704366

$76.49

56

Front Carpet RH

291002085

Unavailable

56

Front Carpet LH

291002084

Unavailable

57

Seat Latch

269001210

Unavailable

58

BUSHING - Call your local BRP dealership

204130095

Unavailable

59

SEAT LATCH SHAFT - Call your local BRP dealership

269001197

Unavailable

60

Circlip 7mm

293370010

$11.99

61

SEAT LATCH SPRING - Call your local BRP dealership

269001153

Unavailable

62

SEAT LATCH CAP - Call your local BRP dealership

269001164

Unavailable

63

Rubber Bumper

293830005

$8.09

64

Cable Clamp

293750029

Unavailable

65

HOOK - Call your local BRP dealership

293750030

Unavailable

66

Plastite Torx Screw #10 X 7/8"

250000207

$2.00

67

Loctite 243, 10 ml

293800060

$21.49
