Polaris 325 MAGNUM 4X4 HDS - A02CD32FB INTAKE and EXHAUST - A02CD32AA/AB/AC/FB (4970147014D09) Diagram

#

Description
Price

1

Screw, Adjusting

3084911

$9.59

1

Screw, Adjusting

3084911

$9.59

2

Nut

3084912

$3.99

2

Nut

3084912

$3.99

3

Asm., Rocker Arm [Incl. 1,2]

3084910

$115.99

4

Shaft, Rocker

3087053

Unavailable

5

Washer, Wave

3085836

$5.59

6

COLLET, VALVE

3084908

$3.99

6

COLLET, VALVE

3084908

$3.99

7

Retainer, Spring

3086893

Unavailable

7

Retainer, Spring

3086893

Unavailable

8

SPRING, VALVE

3086892

$23.99

8

SPRING, VALVE

3086892

$23.99

9

Lever, Release

3086439

Unavailable

10

Spring, Return

3086804

Unavailable

11

Camshaft [Incl. 9,10,12]

3087120

Unavailable

12

PIN, DOWEL

3084899

$7.19

13

Valve, Intake

3085778

Unavailable

14

Valve, Exhaust

3086441

$51.99

15

Guide, Chain

3086445

$35.99

16

Chain, Timing

3086444

$63.99

17

GASKET, TENSIONER

3086448

$6.39

18

Tensioner

3086493

Unavailable

19

BOLT, FLANGE

3083361

Unavailable

20

Sprocket 2

3086443

Unavailable

21

Washer

3083663

Unavailable

22

BOLT, FLANGE

3086449

$7.19

23

Lever

3086446

$79.99

24

Bolt, Pivot

3084924

Unavailable
