Sea-doo 230 Wake 520, 2012 09- Engine Compartment And Accessories Diagram

#

Description
Price

1

LATCH COVER - Call your local BRP dealership

204070036

Unavailable

2

LATCH BASE - Call your local BRP dealership

204070037

Unavailable

3

SPRING - Call your local BRP dealership

204070038

Unavailable

4

LATCH PROTECTOR - Call your local BRP dealership

204070952

Unavailable

5

LATCH CABLE - Call your local BRP dealership

204072793

Unavailable

6

Hex. Screw M6 X 35

207163560

$1.49

7

Stainless Flat Washer M6

234061600

$0.33

8

TIE RAP WITH DART - Call your local BRP dealership

204130098

Unavailable

9

Mount Dart

293730040

$1.04

10

Tie-Rap 180 mm

414115200

$0.11

11

Tie Wrap 368 mm

293750008

$1.04

12

D-SEAL RUBBER - Call your local BRP dealership

204130083

Unavailable

13

GROMMET - Call your local BRP dealership

293720017

Unavailable

14

SHOCK BRACKET - Call your local BRP dealership

204073065

Unavailable

15

HEX. SCREW M5 X 16 - Call your local BRP dealership

207151660

Unavailable

16

ENGINE COVER, WAKE - Call your local BRP dealership | Wake

291003751

Unavailable

17

HINGE ASS'Y - Call your local BRP dealership | Includes 19 to 21

204070127

Unavailable

18

HINGE ROD - Call your local BRP dealership

204070204

Unavailable

19

Cotter Pin M2.5 X 12

204070205

Unavailable

20

Hex. Screw M6 X 25

207162560

$1.47

21

Stainless Flat Washer M6

234061600

$0.33

22

Latch Stud

204130146

$154.99

23

NON-SKID CARPET, ENGINE COVER - Call your local BRP dealership

204073298

Unavailable

24

NON-SKID CARPET, BOW STEP - Call your local BRP dealership

204073299

Unavailable

25

Not Available As Spare Parts

XXX

Unavailable

26

Not Available As Spare Parts

XXX

Unavailable

27

Gas Shock

204073380

Unavailable

28

SHOCK BRACKET - Call your local BRP dealership

204073065

Unavailable

29

HEX. SCREW M5 X 25 - Call your local BRP dealership

207152560

Unavailable

30

230 INSERT-BENCH SEAT - Call your local BRP dealership

291003152

Unavailable

31

TRAY SEAL, METER - Call your local BRP dealership

293200032

Unavailable

32

SCREW 1/4?-20 X 2? - Call your local BRP dealership

204100039

Unavailable

33

FINITION WASHER - Call your local BRP dealership

204100057

Unavailable

34

Phillips Head Screw 1/4 - 20 X 1-1/2"

204100200

$4.00

35

NON SKID CARPET - Call your local BRP dealership

204073368

Unavailable

36

VENT COVER, PORT SIDE - Call your local BRP dealership | Wake

204073812

Unavailable

36

VENT COVER, STARBOARD - Call your local BRP dealership | Wake

204073813

Unavailable

37

Hex. Screw M6 X 35

207163560

$1.49

38

WASHER-FENDER/S.S. - Call your local BRP dealership

204100139

Unavailable

39

Hex. Elastic Stop Nut M6

232561600

$1.15

40

J-TRIM, RED - Call your local BRP dealership | Wake

204073789

Unavailable

41

VENT BASE, PORT SIDE - Call your local BRP dealership

204072801

Unavailable

41

VENT BASE, STARBOARD - Call your local BRP dealership

204072802

Unavailable

42

RIVET_POP 1/8 X ,750 - Call your local BRP dealership

293150036

Unavailable

43

VENT INSERT, PORT SIDE - Call your local BRP dealership

204073029

Unavailable

43

VENT INSERT, STARBOARD - Call your local BRP dealership

204073035

Unavailable
