Sea-doo 180 Challenger SE, 1 x 215 SCIC, 2009 PTO Cover And Magneto _V2 Diagram

#

Description
Price

1

Timing/Drive Cover Ass'y | Includes 1 to 6 This part replaces 420910521.

420481440

$663.40

2

Needle Bushing

420232482

$17.88

3

SPRAY NOZZLE - Call your local BRP dealership

420856012

Unavailable

4

Plug Screw M20 X 1.5

420641317

$12.15

5

Plug Screw M10 X 1

420641323

$13.18

6

Oil Seal

420650315

$11.04

7

Rotary Seal

420650371

$41.01

8

Oil Sieve

420956950

$14.33

9

Torx Flange Screw M6 X 85

420641228

$7.01

10

Torx Flange Screw M6 X 35

420641258

$3.19

11

Clamp

420853414

$17.13

12

Valve Seat Sleeve

420256606

$27.58

13

Compression Spring

420939410

Unavailable

14

Piston Valve

420256638

Unavailable

15

Plug Screw M20 X 1.5

420641052

$35.79

16

O-Ring

420230890

$5.06

17

Pump Shaft Ass'y

420837472

$52.21

18

Oil Pump Rotor 16 mm

420956675

$33.55

19

Needle Pin

420929070

$1.79

20

Oil Pump Cover

420811591

$34.30

21

Torx Flange Screw M6 X 16

420641048

$2.82

22

Impeller

420922801

$16.39

23

Water Pump Housing Ass'Y | Includes 26 to 27 This part replaces 420922686.

420922921

$276.84

24

Water Pump Housing Gasket | Included in gasket kit

420950840

$13.07

25

Torx Flange Screw M6 X 25

420641238

$3.07

26

Torx Flange Screw M6 X 105

420641338

$7.01

27

Oil Filter

420956741

$12.79

28

Oil Filter Cover

420610329

$31.31

29

O-Ring

420850500

$3.01

30

O-Ring

420230923

$2.97

31

Oil Filter Screw Kit

295501207

$37.28

32

O-Ring

420950860

$3.67

33

Stator Plate This part replaces 420889721.

420889726

$319.49

34

Magneto Flywheel

420296900

$461.99

35

Torx Flange Screw M6 X 35

420641258

$3.19

36

Retaining Plate

420926300

$14.90

37

Torx Flange Screw M6 X 16

420641048

$2.82

38

Trigger Wheel

420966851

$17.13

39

Starter Double Gear 87/86T

420834871

$287.28

40

Hex Screw

295501162

$13.16

41

Timing Drive Cover Gasket (1603 NA) | Included in gasket kit

420931130

$22.36

42

Crankshaft Position Sensor Ass'y | Includes 10 to 11

420966570

$106.69

43

Torx Flange Screw M6 X 16

420641048

$2.82

44

Ball Bearing With Bellows Ass'y | Includes 50 to 52

420832648

$131.31

45

O-Ring

420631612

$4.04

46

Gear Clamp

420851653

$7.01

47

Gear Clamp 46.8-50.0MM

420853023

$7.01

48

Formed Hose This part replaces 420922825.

420922828

$41.76

49

Oetiker Clamp

420851687

$10.82

B

Loctite 243, 10 ml

293800060

$21.49

C

Sealant Loctite 648

219703000

$41.01

N

Dow Corning 111, 150 g

413707000

$59.99

O

Not Available As Spare Part - Friction Washer

Unavailable

P

Loctite 5910, 300 ml

293800081

$57.99
