Description

Price

411

WASHER-PLAIN,6MM

411S0600

$2.06

11051

BRACKET,HORN

11051-3728

$13.40

13107

SHAFT

13107-3754

$6.11

21176

SENSOR,SPEEDOMETER

21176-3713

$228.70

25008

BRACKET-METER

25008-3709

$50.01

27003

HORN

27003-3704

$73.01

27010

SWITCH,FUEL LEVEL

27010-3742

$312.92

27010A

SWITCH,OIL LEVEL

27010-3753

$159.07

41073

WHEEL-ASSY,PADDLE

41073-3701

$16.84

92037

CLAMP

92037-1173

$3.49

92037A

CLAMP

92037-3009

$3.70

92072

BAND,L=201

92072-3778

$1.84

92075

DAMPER

92075-1446

$4.69

92151

BOLT,6X10

92151-3704

$4.20

92151A

BOLT,5X10

92151-3707

$3.32

92160

DAMPER,METER

92160-3881

$13.66

92170

CLAMP

92170-3718

$13.67

92170A

CLAMP

92170-3734

$15.26

92200

WASHER,5.9X16X1.5

92200-3714

$2.14

25031B

METER-ASSY

25031-3710

Unavailable

25031C

METER-ASSY

25031-3711

Unavailable

Kawasaki 1100 STX Meters Diagram

WASHER-PLAIN,6MM

BRACKET,HORN

SHAFT

SENSOR,SPEEDOMETER

BRACKET-METER

HORN

SWITCH,FUEL LEVEL

SWITCH,OIL LEVEL

WHEEL-ASSY,PADDLE

CLAMP

CLAMP

BAND,L=201

DAMPER

BOLT,6X10

BOLT,5X10

DAMPER,METER

CLAMP

CLAMP

WASHER,5.9X16X1.5

METER-ASSY

METER-ASSY
