KTM 105 SX <2008> ENGINE CASE Diagram

#

Description
Price

1

ENGINE CASE CPL. 85 SX 2008

47030000144

$391.85

18

COPPER GASKET 10,2X14X2 MM 01

0603101420

$3.08

19

O-RING 16,00X3,00 NBR 70

0770160030

$2.05

20

OIL FILLER CAP M24x3 W. O-R

58030120000

$8.03

21

OIL DRAIN PLUG M10 WS=13

46030021100

$13.46

22

ANGLE PIECE 50CCM LC 2001

45130022000

$5.88

23

DOWEL 13X13

47030023100

$5.10

24

DOWEL 7X9X10

45130023000

$5.23

25

INNER CLUTCH COVER GASKET

47030025000

$17.48

26

OUTER CLUTCH OVER 85 SX 06

47030101100

$84.80

27

GASKET FOR OUTER CLUTCH COVER

47030027100

$11.96

39

GASKET F. ENGINE CASE 85 SX 03

47030039000

$17.57

52

WATER PUMP COVER 85 SX 2003

47035052000

$41.04

53

GASKET FOR WATER PUMP COVER 03

47035053000

$10.84

56

SPRINGHOLDER

47003071000

$9.06

57

CU-SEAL RING DIN7603-6X10X1

0603061001

$2.05

70

DOWEL 14,5X19

47030023000

$7.00

71

HH COLLAR SCREW M 6X10 WS=8

0015060103

$3.08

73

HH COLLAR SCREW M 6X20 WS=8

0015060203

$3.08

74

HH COLLAR SCREW M 6X25 WS=8

0015060253

$3.08

75

HH COLLAR SCREW M 6X30 SW=8

0015060303

$3.08

76

HH COLLAR SCREW M 6X35 WS=8

0015060353

$3.08

77

HH collar screw M6x40 TX30

0025060406

$3.08

78

HH COLLAR SCREW M 6X45 WS=8

0015060453

$2.05

82

HH COLLAR SCREW M 6X65 WS=8

0015060653

$2.05

99

GASKET SET CPL. 85/105SX 04

47030099100

$191.67

2

CLUTCH COVER 85 SX 06

47030001100

$170.35
