Sea-doo GTI 90, 2018 Electrical GTI - 900 HO ACE Diagram

Voltage Regulator | For replacement, refer to service bulletin 2005-5

710001103

$142.99

Support

278003485

$13.17

Elastic Nut Housing M8 | Included 10a6 to 10a6a

269501943

$6.67

Hexagonal Screw M8 X 30

250000888

$3.17

Torx Screw Plastite M6

250000466

$6.98

Starter Relay

278003012

$42.49

Connector Plug

710004904

$8.79

Battery Ass'y, 18 Amperes | XT Models, Includes 72 To 73

410301203

$154.99

Battery Bolt Kit

250000282

$7.29

Hexagonal Cap Screw M6 X35

250000399

$4.44

Battery Support

278003671

$28.99

Strap

293850124

$20.99

Elastic Stop Nut M6, Brass

232561200

$4.23

Tie-Rap 180 mm

414115200

$0.11

Tie Rap 300mm

293750053

$2.11

Tie-Rap 180 mm

414115200

$0.11

Mount Dart

293730040

$1.04

Torx Flange Screw M6 X 16

420641588

$2.11

Wiring Harness

278003566

$589.99

Battery Ground Cable

278003408

$38.99

Hex. Screw M10 X 20, Scotch Grip

207302060

$4.02

Flat Washer 10 mm, Stainless

234000600

$1.46

Starter Cable

278003409

$39.99

Elastic Stop Nut M6, Brass

232561200

$4.23

Stainless Flat Washer M6

234061600

$0.33

LH Throttle Sensor

278002284

$119.99

Hex. Screw M6 X 12, Scotch Grip

207361260

$0.58

Stainless Flat Washer M6

234061600

$0.33

LCD Gauge

278003580

$979.99

Throttle Position Sensor

278002283

$119.99

Switch LH Sport/Eco

278002768

$83.49

Switch RH Mode/Set

278002602

$126.99

Steering Harness Ass'y

278003559

$349.99

Terminal Dess One-Wire | Except Model Europe

515178840

$83.49

Safety Nut (DESS Switch)

278002963

$3.28

Safety Lanyard Ass'y, RFID

278003400

$84.99

Safety Lanyard Ass'y, Learning / RFID

278003401

$84.99
