Can-Am Defender MAX HD10 - Limited - 2020 Cab - Air Conditioner System - Cab LTD Diagram

Description

Price

1004

Hex. Elastic Stop Nut M8

232581414

$0.54

1005

Hex. Flange Elastic Nut M8

233281414

$1.31

1006

Flat Washer 8 mm

234082410

$1.27

1010

LH Manifold Ass'y | Includes 1010 to 1010a

705800649

$18.63

1010a

LH Manifold

705800428

$18.63

1012

Tuflok Plastic Rivet

293150230

$1.39

1015

RH Manifold Ass'y | Includes 1015 to 1015a

705800650

$18.63

1030a

Grille Scoop

705800436

$22.36

1030b

Duct Ventilation Kit

705800706

$9.45

1030c

Duct Ventilation Kit

705800610

$67.13

1030h

Ventilation Duct Kit

705800707

$67.13

1030k

Ventilation Duct Kit

705800707

$67.13

1040a

Grille Scoop

705800436

$22.36

1070

Intake Duct

705800377

$24.60

1075

Lower Intake Fitting

705800437

$17.88

1080

Upper Intake Fitting

705800438

$49.97

1085

Upper Intake Duct

705800439

$30.57

1090

Air Filter

705800395

$32.06

1092

Torx Screw K50 X 16

250000720

$1.60

1095

Norma Gear Clamp

293650118

$11.18

1100

LH Upper Console Support

705800571

$58.18

1110

RH Upper Console Support

705800443

$58.18

1115

Hex. Flange Screw M6 X 20

207662044

$1.91

1120

Lower Console Support

705800444

$18.63

1125

Hex. Flange Screw M6 X 20

207662044

$1.91

1130

Cup Holder

705800452

$35.79

1134

Torx Truss Screw K40 X 12

250000577

$2.00

1140

Cup Retainer

707900036

$6.19

4200

Central Adapter

705800501

$24.60

4205

Front Ventilation Grille

705800425

$10.85

4210

Torx-Truss Pt K40 X 16

250000759

$2.00

4240

Side Grille Support

705800426

$4.81

4250

Central Grille Support

705800427

$20.12

4255

Tuflok Plastic Rivet

293150230

$1.39

4260

LH Lower Grille Support

705800455

$20.12

4270

Stainless Steel Flat Washer

234062670

$2.00

4280

Torx Screw M6 X 20

250000722

$1.54

5150a

Gasket, Neoprene 2000Mm Long

219704476

$14.51

5160a

Neoprene Seal (1PAC=3M)

219704364

$26.09

5240

LH Insulating Foam

705800278

$7.67

5310a

Gasket, Neoprene 2000Mm Long

219704476

$14.51
