Ski-Doo MXZ 120 - 2023 Front Suspension Arm Diagram

#

Description
Price

1

Upper A Arm

3704-321

$82.99

2

RH Lower A-Arm

3704-330

$109.99

2

LH Lower A-Arm

3704-331

$109.99

3

Washer 5/16

8050-277

$0.37

4

Inner Axle A-Arm

3603-615

$14.99

5

Bushing

0605-451

$5.49

6

Cap Screw HH 3/8-16 X 6.125 G5 Z&Y

1623-983

$4.36

7

Hex Flange Nut

8047-486

$1.16

8

Shock / Spring Ass'y

4703-356

$70.49

9

Cushion

1603-531

$4.89

10

Screw HH 3/8

8002-225

$1.16

11

Hex Nut 3/8-16

8041-486

$0.49
