Can-Am Defender MAX HD10 - DPS_XT_Lone Star - 2021 Body - Skid Plate Diagram

Description

Price

2020

Central Skid Plate

705009151

$55.35

2025

Pop Rivet 3/16" | DS 650 X

293150104

$1.49

2030

Connection Plate

705010884

$29.20

2040

Rear Skid Panel

705017205

$147.66

2045

Pop Rivet 3/16" | DS 650 X

293150104

$1.49

2050

Lateral Skid Plate

705010422

$83.05

2055

Pop Rivet 3/16" | DS 650 X

293150104

$1.49

2060

Rear Side Skid Plate

705010587

$83.05

2065

Pop Rivet 3/16" | DS 650 X

293150104

$1.49

2070

Rear Central Skid Plate

705010588

$59.97

2075

Pop Rivet 3/16" | DS 650 X

293150104

$1.49

5500

Front Roof

705800066

$491.51

5501a

Was 293250361 Gasket

219704379

$73.82

5502a

Outer Seal

705800054

$36.89

5510

Rear Roof

705800067

$332.28

5511a

Outer Seal

705800054

$36.89

5512a

Outer Seal

705800054

$36.89

5520

Torx Truss M8 X 25

250000874

$1.74

5521

Flat Washer 8 mm

234082410

$1.11

5522

Hex. Nut M8

232081414

$0.60
