Can-Am Outlander MAX 1000R EFI - LTD - CE, 2022 Body - Front Storage Tray Diagram

Description

Price

Rear Storage Box

708300674

$93.99

Storage Cover Ass'y

715007683

$55.99

Rear Panel

708300150

$38.99

Gasket

293200177

$16.99

Handle Latch

708201250

$14.49

Tool Kit

704700168

$40.99

90c

Socket Wrench 14/16MM

529000085

$6.55

90g

Screw Driver

529000021

$3.29

160

Adjustment Wrench

529000035

$2.09

170

Winch Instruction Guide

219002430

Unavailable

310

Rear Bumper Ass'y | Except North America

715007682

$60.99

340

Insert Half Hex Body M6 x 1.0

250100199

$3.19

395

Flange Elastic Nut M5

233251434

$2.00

400

Panel Nut M6 X 1.0

250100198

$2.11

410

Torx Truss Screw M6 X 25

250000807

$2.11

420

LH Cargo Support

705006997

$55.99

430

RH Cargo Support

705006998

$55.99

440

Hex. Flange Screw M6 X 20

207662044

$2.00

445

Hex. Flange Screw M6 X 25

207662544

$0.64

450

Hex. Flange Screw M6 X 16

207661644

$0.74

460

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

465

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

470

Hex. Flange Screw M6 X 16, Scotch Grip

207561646

$1.90

480

LH Side Member

705018144

$30.99

490

RH Side Member

705018146

$30.99

500

Hex. Flange Screw M8 X 20

207682044

$1.15

510

Hex. Flange Elastic Nut M8

233281414

$1.47

515

Hex Flange Screw M8 X 25 S.Grip

250001016

$1.46

520

Tuflok Plastic Rivet

293150230

$1.47

540

License Plate Support

705018142

$15.49

570

Reflector Support

708200987

$4.09

580

Red, Reflector

705016982

$14.49
