Description

Price

1

Black, Steering Post

1705-579

$129.99

2

Handle Grip

1605-174

$17.99

3

Plug

2623-200

$0.40

4

Handlebar Pad

1605-107

$19.99

5

Handlebar Pad Cover

1705-444

$43.99

6

Cap Screw 1/4 X 0.875

8020-041

$8.59

7

Harness Guide

0645-826

$12.49

8

Black, Steering Support Bracket

0705-896

$19.99

9

Steering Post Bearing

0605-444

$5.59

10

Elastic Stop Nut 1/4-20

8047-366

$0.49

11

Black, RH Steering Support

6716-074

$36.99

11

Black, LH Steering Support

6716-075

$36.99

12

Elastic Stop Nut 1/4-20

8047-426

$0.76

13

Flat Washer

8050-247

$0.72

14

Cap Screw 5/16-18

8020-134

$1.79

15

Tie Rod Ass'y

1705-585

$132.99

16

LH Hex Jam Nut 5/16

0623-260

$1.37

17

RH Hex Jam Nut 5/16

0123-144

$0.37

18

Hex Jam Nut 5/16

8040-456

$0.76

19

Fuel Pump Bracket

2670-665

$5.59

20

Tie-Rap 180 mm

414115200

$0.11

21

Flat Washer 1/4

8050-212

$0.85

22

Lock Washer 1/4

8053-212

$0.25

23

Cap Screw 5/16-18

8020-131

$1.89

Ski-Doo 007 - MXZ 200 - Europe, 2023 Steering Diagram

Black, Steering Post

Handle Grip

Plug

Handlebar Pad

Handlebar Pad Cover

Cap Screw 1/4 X 0.875

Harness Guide

Black, Steering Support Bracket

Steering Post Bearing

Elastic Stop Nut 1/4-20

Black, RH Steering Support

Black, LH Steering Support

Elastic Stop Nut 1/4-20

Flat Washer

Cap Screw 5/16-18

Tie Rod Ass'y

LH Hex Jam Nut 5/16

RH Hex Jam Nut 5/16

Hex Jam Nut 5/16

Fuel Pump Bracket

Tie-Rap 180 mm

Flat Washer 1/4

Lock Washer 1/4

Cap Screw 5/16-18
