Ski-Doo MXZ 120 - Europe, 2023 Engine - Piston and Crankshaft Diagram

#

Description

Price

1

PISTON - Call your local BRP dealership

3020-013

Unavailable

1

Piston Oversized (0.25) Optional

3020-015

$82.81

1

Piston Oversized (0.50) Optional

3020-016

$82.81

2

Ring Piston Set

3020-010

$52.96

2

Ring,Piston Oversized (0.25) Optional

3020-011

$44.75

2

Ring,Piston Oversized (0.50) Optional

3020-012

$44.75

3

Piston Circlip

3020-115

$2.76

4

Piston Pin

3020-014

$17.88

5

Connecting Rod Ass'y

3021-720

$148.99

6

Cap Screw

3020-032

$8.83

7

Crankshaft Ass'y

3020-029

$393.99

8

Woodruff Key

3020-098

$18.63

9

Shim Crankshaft T (T=0.1)

3020-030

$4.04
