Ski-Doo 006 - MXZ 120 - Europe, 2023 Chassis, Footrest and Rear Bumper Diagram

#

Description
Price

1

Black, Tunnel Ass'y

4707-392

$1.00

2

Black, Front End Ass'y

6716-497

$389.99

3

Zinc Rivet

8060-484

$0.48

4

RH Reinforced Tunnel Plate

2706-156

$45.99

4

LH Reinforced Tunnel Plate

2706-157

$45.99

5

Black, Tunnel Cover Plate

2706-158

$24.49

6

Self Tapping Screw 1/4-20X1/2

0623-892

$1.27

7

Black, Front Belly Pan Bracket

6706-367

$25.99

8

Rack Trim 36

0706-371

$25.99

9

Machine Screw

8477-620

$0.62

10

Voltage Regulator

0630-409

$134.99

11

Elastic Stop Nut 1/4-20

8047-366

$0.49

12

Cap Screw 1/4-20

8020-040

$2.33

13

RH Footrest Support Bracket

2706-180

$14.49

13

LH Footrest Support Bracket

2706-181

$14.49

14

Black, RH Footrest

6716-354

$32.99

14

Black, LH Footrest

6716-355

$65.99

15

Zinc Rivet

8060-486

$0.48

16

Cover

2706-217

$41.99

17

Tie-Rap 180 mm

414115200

$0.11

18

RH Footrest Support

4706-824

$49.99

18

LH Footrest Support

3706-773

$45.99

19

Black, RH Rear Bumper End Cap

4706-262

$19.49

19

Black, LH Rear Bumper End Cap

4706-263

$16.99

20

Black, Rivet

8060-706

$0.48

21

Black, Hole Plug 3/8 Dia

0623-562

$1.89

22

Decal Amber Reflector

6606-819

Unavailable

23

Warning Decal

3611-754

Unavailable

24

Black, Rear Bumper

3706-006

$43.99

25

Flat Washer

0123-802

$0.23

26

Snow Guard

1616-354

$31.99

27

Black, Pop Rivet

8060-708

$1.48

28

Flag Safety Ass'y

6706-408

Unavailable

29

Flat Washer

8050-247

$0.72

30

Cap Screw 5/16-18

8020-134

$1.79

31

Self Tapping Screw 10X1/2

0623-301

$0.25

32

Black, RH Belly Pan Support

6706-552

$32.99

32

Black, LH Belly Pan Support

6706-553

$32.99

33

RH Outer Reinforcement Plate

6706-548

$30.99

33

LH Outer Reinforcement Plate

6706-549

$30.99

34

Inner Reinforcement Plate

6706-440

$18.49

35

Black, Bracket

6706-441

$50.99

36

Cap Screw 5/16-18

8020-131

$1.89

37

Elastic Stop Nut 1/4-20

8047-426

$0.76

38

Tether Switch

0630-138

$84.99

39

Tether Switch Cord

0630-139

Unavailable

40

Heat Sensor Clamp M12

3008-040

$2.59

41

Decal Jet Chart 120

6621-942

$14.49

42

X-Brace Axle

4604-452

$18.49

43

Black, Front Bumper

6706-274

$55.99

44

Cap Screw 5/16-18

1623-566

$1.91

45

Hex Flange Elastic Nut M6X1.0

8427-602

$0.25
