Sea-doo FISH PRO, 2019 Hull Extension and Ladder Diagram

#

Description
Price

50a

Hull Extension

292002138

$177.58

50b

Body Extension

292002139

$132.81

50c

Reinforcement Body Extension

292002140

$52.21

50d

Hexagonal Cap Screw M6.8 X 25

250001070

$3.51

50e

Extension Float

292002529

$103.70

50f

Extension Carpet

292002210

$110.42

50g

Plastite Hex. Screw M6.8 X 35

243163560

$4.15

50h

Cleat

291004597

$22.36

50i

Flat Washer 8 mm, Stainless

250200175

$1.48

50j

Hex. Elastic Nut M8 Brass

232581200

$1.48

50k

Linq Bases Kit

295100858

$24.60

50l

U-Clamp

292000933

$37.28

50m

Flat Washer M8.5 x 18

293050001

$1.48

50n

Rubber Washer

293830037

$2.68

50o

Flat Washer 8 mm, Stainless

250200175

$1.48

50p

Hex. Elastic Nut M8 Brass

232581200

$1.48

50q

Ladder Attachment

292002113

$7.57

50r

Truss Cone Torx Screw M6 X 30

250000924

$7.06

50s

Stainless Flat Washer M6

234061600

$0.28

50t

Flat Washer M6.6 X 22

250200022

$2.15

50u

Elastic Stop Nut M6, Brass

232561200

$4.03

60

Hexagonal Head Cap Screw M8 X 45

250000782

$2.70

62

Flat Washer

279000336

$9.58

64

Screw Torx M6.81 X 30

250001007

$1.85

66

Hexagonal Cap Screw M6.8 X 25

250001070

$3.51

68

Hex. Screw M6 x 80

207068060

$2.28

70

Stainless Flat Washer M6

234061600

$0.28

72

Hex. Elastic Stop Nut M6

232561600

$1.06

74

Hexagonal Cap Screw M6.8 X 25

250001070

$3.51

1080>1080d

Ladder Ass'y | Includes 1100a to 1100a4

295100869

$246.24

1080a

Spring

292002107

$24.60

1080b

Hex. Screw M6 x 80

207068060

$2.28

1080c

Stainless Flat Washer M6

234061600

$0.28

1080d

Hex. Elastic Stop Nut M6

232561600

$1.06
