Can-Am Commander MAX 1000R EFI - 2019 Cab Interior Commander MAX - Front Section Diagram

#

Description
Price

350

Front Side Dash Panel

707900193

$62.66

360

Tuflok Plastic Rivet

293150230

$1.39

370

Torx Screw M6 X 20

250000722

$1.54

380

Insert Half Hex Body M6 x 1.0

250100199

$2.91

390

Stainless Steel Flat Washer

234062670

$2.00

400

RH Fixe Side Console

707900021

$68.63

400

RH Fixe Side Console | LTD Model

707900098

$79.07

410

Tuflok Plastic Rivet

293150230

$1.39

440

Torx Screw M6 X 20

250000722

$1.54

450

Insert Half Hex Body M6 x 1.0

250100199

$2.91

470

Stainless Steel Flat Washer

234062670

$2.00

480

Washer

506151252

$3.01

500

LH Front Upper Floor

707900175

$75.34

510

Torx Screw M6 X 20

250000722

$1.54

520

Torx Screw M6 X 20

250000712

$2.00

525

Torx Screw M6 X 25

250000758

$2.00

530

Hex. Flange Elastic Nut M6

233261494

$1.45

540

Stainless Steel Flat Washer

234062670

$2.00

550

Panel Nut M6 X 1.0

250100198

$1.99

560

Stainless Steel Flat Washer

234062670

$2.00

570

Torx Screw K50 X 16

250000720

$1.60

580

Flat Washer 6 mm

234062410

$0.73

835

Torx Truss Screw M6 X 30

250000843

$2.00

850

RH Front Floor

707900004

$74.60

860

Torx Screw M6 X 20

250000722

$1.54

870

Torx Screw M6 X 20

250000712

$2.00

875

Torx Screw M6 X 25

250000758

$2.00

880

Hex. Flange Elastic Nut M6

233261494

$1.45

890

Stainless Steel Flat Washer

234062670

$2.00

900

Panel Nut M6 X 1.0

250100198

$1.99

910

Stainless Steel Flat Washer

234062670

$2.00

920

Oblong Grommet

705003668

$5.21

930

Torx Screw K50 X 16

250000720

$1.60

940

Flat Washer 6 mm

234062410

$0.73

1050

Upper Seal

293250252

$2.59

1060

Bottom Seal

293250253

$2.79

1300

SUPPORT_PANEL LH - Call your local BRP dealership

707900029

$11.63

1310

Panel Nut M6 X 1.0

250100198

$1.99

1320

Torx Screw M6 X 20

250000722

$1.54

1330

Torx Screw K50 X 16

250000720

$1.60

1340

Flat Washer

224060201

$1.12

1350

Hex. Screw M6 X 25

207162544

$1.01

1360

Flat Washer

224061201

$1.27

1370a

Was 293200017 Neoprene Seal

219704365

$135.79

1400

SUPPORT_PANEL RH - Call your local BRP dealership

707900030

Unavailable

1410

Panel Nut M6 X 1.0

250100198

$1.99

1420

Torx Screw M6 X 20

250000722

$1.54

1430

Torx Screw K50 X 16

250000720

$1.60

1440

Flat Washer

224060201

$1.12

1450

Hex. Screw M6 X 25

207162544

$1.01

1460

Flat Washer

224061201

$1.27

1470a

Was 293200017 Neoprene Seal

219704365

$135.79

2200

Dashboard Ass'y

715001250

$71.61

2200

Dashboard Ass'y

715001250

$71.61

2210

Torx Screw Truss Head K50X20 T20

250000760

$2.00

2220

Stainless Steel Flat Washer

234062670

$2.00

2230

Support Plate

705003841

$0.91

2240

Edge Clip

517302785

$0.81

2250

Torx Screw M6 X 20

250000722

$1.54

2260

Panel Nut M6 X 1.0

250100198

$1.99

2290

Was 271000110 Protection Trim

219704353

$14.58

2300

Central Dashboard Ass'y

715002178

Unavailable

2300

Central Dashboard Ass'y

715002187

$34.30

2310

Torx Screw M5 X 20

250000724

$1.60

2320

Panel Nut M5 X 0.8

250000958

$4.00

2330

Tuflok Plastic Rivet

293150230

$1.39

2350

Gauge Support | LTD Model

707900066

$35.04

2360

Torx Screw K50 X 16

250000720

$1.60

2370

Push Nut

732610072

$1.97

2500

Storage Bin

707900009

$103.70

2500

Storage Bin | XT

707900046

$91.01

2510

Hex. Flange Screw M6 X 20

207662034

$2.00

2520

Panel Nut M6 X 1.0

250100198

$1.99

2530

CAP - Call your local BRP dealership

414859400

Unavailable

2540

Rubber Bumper

293830005

$6.12

2600

LUGGAGE COVER KIT - Call your local BRP dealership

707900221

Unavailable

2610

Latch

707900031

$7.57

2620

Trim Glove Box

707900062

$16.39

3600

Torx Screw M5 X 14

250000742

$1.37

3610

Flat Washer

250200040

$1.76

3615

Hex. Flange Screw S.Grip M6 X 20

207562054

$2.00

3620

Hex. Flange Screw M8 X 20

207682044

$1.06

3625

Hex. Flange Elastic Nut M8

233281414

$1.31
