Can-Am Outlander 570 EFI - XMR - 2021 Body - Rear Section Diagram

#

Description
Price

20

Hex. Flange Screw M6 X 20

207662054

$0.96

30

Flange Elastic Nut M6

233261434

$4.15

135

Flat Washer

224061201

$1.27

140

Panel Nut M6 X 1.0

250100198

$1.99

320

Black, Rear Luggage Rack

715005986

$214.15

330

Torx Truss Screw M8 X 50

250000761

$7.09

340

Elastic Flange Nut M8

233281464

$0.96

350

Hex Flange Screw M8 X 25 S.Grip

250001016

$1.22

475

Rubber Pad

293830163

$7.81

480

Rear Storage Box Kit

715007980

$206.69

480c

LH Box Rear Latch

705007448

$9.91

480d

RH Box Rear Latch

705007921

$9.85

480e.a

Was 715900411 Neoprene Seal | Outlander MAX

219704452

$34.30

480f

Retaining Rod

705007531

$70.87

480g

Panel Nut M6 X 1.0

250100198

$1.99

480h

CAP - Call your local BRP dealership

414859400

Unavailable

485

Heat Deflector Sheet

705007487

$3.81

487

Panel Nut M6 X 1.0

250100198

$1.99

525

Rear Facia | Except Model- Europe

705005576

$41.01

530

Red Reflector

705011221

$11.96

535

Stopper Rubber

705014429

$6.09

540

Flange Elastic Nut M5

233251434

$1.91

580

Torx Truss Screw M6 X 25

250000807

$2.00

590

Torx Screw M6 X 20

250000722

$1.54

770

Tuflok Plastic Rivet

293150230

$1.39

822

Elastic Flange Nut M8

233281464

$0.96

1080

Tool Kit

704700168

$40.99

1080c

Socket Wrench 14/16MM

529000085

$6.55

1080f

Screw Driver

529000021

$3.19

1110

Adjustment Wrench

529000035

$2.19
