09- Body - Rear Section
Can-Am 003 - Outlander 570 EFI - STD - International, 2020 09- Body - Rear Section Diagram
#
20
Hex. Flange Screw M6 X 20
207662054
Unavailable
30
Flange Elastic Nut M6
233261434
Unavailable
70
LH Structural Footboard
705011540
Unavailable
80
RH Structural Footboard
705011542
Unavailable
90
Carriage Bolt M6 X 35
207763554
Unavailable
100
Flat Washer 6 mm
234062410
Unavailable
110
LH Step
705007040
Unavailable
120
RH Step
705007039
Unavailable
130
Hex. Flange Screw M6 X 16
207661654
Unavailable
135
Flat Washer
224061201
Unavailable
140
Panel Nut M6 X 1.0
250100198
Unavailable
320
Rear Luggage Rack Ass'y | Except Model North America
715005988
Unavailable
330
Torx Truss Screw M8 X 50
250000761
Unavailable
340
Elastic Flange Nut M8
233281464
Unavailable
350
Hex Flange Screw M8 X 25 S.Grip
250001016
Unavailable
475
Rubber Pad
293830163
Unavailable
480a
Storage Cover | Model-Europe International
715004412
Unavailable
480b
Storage Cover | Model-Europe International
715004412
Unavailable
480c
LH Box Rear Latch
705007448
Unavailable
480d
RH Box Rear Latch
705007921
Unavailable
480e
Was 715900411 Neoprene Seal | Outlander MAX
219704452
Unavailable
480f
Retaining Rod
705007531
Unavailable
480g
Panel Nut M6 X 1.0
250100198
Unavailable
480h
CAP - Call your local BRP dealership
414859400
Unavailable
485
Heat Deflector Sheet
705007487
Unavailable
487
Panel Nut M6 X 1.0
250100198
Unavailable
525
Rear Facia | Except Model- Europe
705005576
Unavailable
530
Red Reflector
705011221
Unavailable
535
Stopper Rubber
705014429
Unavailable
580
Torx Truss Screw M6 X 25
250000807
Unavailable
590
Torx Screw M6 X 20
250000722
Unavailable
770
Tuflok Plastic Rivet
293150230
Unavailable
