Can-Am Maverick Turbo - XRC - 2020 Front Suspension Diagram

Orange Crush, LH Upper Suspension Arm

706203932

$253.82

Orange Crush, RH Upper Suspension Arm

706203933

$253.82

Suspension Arm Bushing

706204409

$8.29

Interior Bushing

706202257

$9.22

Wear Plate

706202300

$2.31

Grease Fitting 90°

293550056

$1.37

Deep Black, LH Front Suspension Arm Ass'y With Balljoint This part replaces 706202919.

715010612

$253.82

Deep Black, RH Front Suspension Arm Ass'y With Balljoint This part replaces 706202920.

715010611

$253.82

Flange Screw M12 X 85

250000859

$3.95

Flange Screw M12 X 145

250000861

$5.47

Elastic Flange Nut M12

233221466

$2.15

Ball Joint

706203084

$35.35

Ball Joint

706202045

$35.35

Flange Screw M12 X 60

250000857

$6.08

Elastic Flange Nut M12

233221466

$2.15

LH Front Knuckle

706204785

$198.43

RH Front Knuckle

706204786

$147.66

Wear Plate

706202502

$2.75

Circlip

293370035

$2.55

Nut M12

250100099

$1.64

Hardened Washer

706200281

$2.34

Cotter Pin

211400017

$0.25

Hex. Flange Screw M10 X 50

207605044

$4.39

Hex. Flange Elastic Nut M10

233201436

$1.74

Stabilizer Bar Ass'y

703501043

$119.97

LH Stabilizer Bar Link

706203611

$67.66

RH Stabilizer Bar Link

706203612

$67.66

Bushing_Stabilizer Bar

706204565

$9.22

Grease Fitting 90°

293550056

$1.37

Clamp

706202460

$6.45

Support Plate

706202551

$4.60

Hex. Flange Screw M12 X 95

250000876

$5.54

Elastic Flange Nut M12

233221466

$2.15

Elastic Stop Nut M12

232521416

$1.40

Conical Spring Washer M12

250200167

$3.04

Black, Link

706202708

$55.35

LH A-Arm Protector

706203381

$129.20

RH A-Arm Protector

706203382

$129.20

Stainless, Torx Screw M6 X 30

250000842

$1.74

Hex. Flange Elastic Nut M6

233261494

$1.26

Collar

293750075

$7.37
