Kawasaki Z250SL Swingarm Diagram

#

Description
Price

11012

CAP,SWING ARM

11012-1259

$17.61

11012A

CAP,CHAIN ADJUSTER,F.S.BLACK

11012-1871-18R

$22.05

33001

ARM-COMP-SWING,F.S.BLACK

33001-0613-18R

$466.75

33032

SHAFT-SWING ARM,14X254

33032-0038

$54.64

33040

ADJUSTER-CHAIN,OUTER,RH

33040-0044

$21.58

33040A

ADJUSTER-CHAIN,INNER

33040-0045

$15.93

33040B

ADJUSTER-CHAIN,OUTER,LH

33040-0046

$21.58

42036

SLEEVE,15X20X49

42036-0736

$16.51

42036A

SLEEVE,SWING ARM

42036-1064

$19.97

55020

GUARD,CHAIN

55020-0912

$24.76

92015

NUT,8MM

92015-1364

$2.99

92015A

NUT,14MM

92015-1407

$7.54

92015B

NUT,8MM

92015-1658

$3.71

92046

BEARING-NEEDLE

92046-0038

$21.08

92151

BOLT,SOCKET,6X18

92151-1149

$5.86

92154

BOLT,25X19

92154-1241

$20.36

92200

WASHER,8.5X16X1.2

92200-0905

$1.10

92200A

WASHER,15.2X31X3.2

92200-0953

$2.44

92210

NUT,POP,6MM,L=15

92210-1397

$4.81
