1979 Yamaha YZ400F (YZ400F) Seat Diagram

← All diagrams

Find the part on the Seat diagram for your 1979 Yamaha YZ400F (YZ400F), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Yamaha YZ400F (YZ400F) Seat Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

SEMI-DBL-SEAT ASSEMBLY

(2X4-W2473-00-00)

1
Out of stock

2

. COVER, SM-DBL SEAT

3R4-24771-00-00

1
Out of stock

3

BOLT(3RV)

97014-06035-00

1
Out of stock

4

NUT, SELF-LOCKING

95617-06100-00

1
Out of stock

5

YBS66-6 WASHER, PLAIN

92990-06200-00

1
Out of stock

6

BRACKET, SEAT

1M1-24748-00-00

1
Out of stock

7

BRACKET, SEAT

1W1-24738-00-00

1
Out of stock

8

BOLT (583)

90101-06304-00

1
Out of stock

9

DAMPER, SEAT

509-24724-00-00

1
Out of stock
