Yamaha YT125N 1985 HANDLE SWITCH - LEVER Diagram

#

Description
Price

1

HOLDER, LEVER (L.H)

214-82911-01-00

$45.93

2

LEVER 1

23X-83912-02-00

$20.03

3

LEVER, LOCK

3X3-83965-00-00

$25.97

4

COLLAR, LEVER

3X3-83913-00-00

Unavailable

5

BOLT, HEXAGON

97017-06025-00

$2.78

6

NUT (J17)

95380-06800-00

$6.28

7

WASHER, SPRING

92995-06100-00

$2.95

8

BOLT, HEXAGON

97013-06022-00

$1.12

9

WASHER, SPRING

92995-06100-00

$2.95

10

LEVER HOLDER ASSEMBLY 2

5V6-82720-00-00

Unavailable

11

. LEVER, THROTTLE

5V6-42138-00-00

Unavailable

12

. SPRING

5V6-42147-00-00

Unavailable

13

. LEVER, THROTTLE CON

5V6-42154-00-00

Unavailable

14

WASHER, SPRING

92995-06100-00

$2.95

15

NUT, HEXAGON

95380-06600-00

$4.11

16

BOLT, HEXAGON

97017-06025-00

$2.78

17

WASHER, SPRING

92995-06100-00

$2.95

18

SCREW,PAN HEAD (646)

98580-05012-00

Unavailable
