1967 Yamaha YL2 (YL2_100) Front Fork Diagram

← All diagrams

Find the part on the Front Fork diagram for your 1967 Yamaha YL2 (YL2_100), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1967 Yamaha YL2 (YL2_100) Front Fork Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

. TUBE, OUTER 1

164-23126-00-81

1
Out of stock

2

. TUBE, OUTER 2

164-23136-00-81

1
Out of stock

3

. METAL, SLIDE 1

164-23125-00-00

1
Out of stock

4

. O-RING

164-23147-00-00

1
Out of stock

5

OUTER NUT

164-23150-00-00

1
Out of stock

6

. TUBE, INNER 1

164-23124-00-00

1
Out of stock

7

. OIL SEAL

164-23145-01-00

1
Out of stock

8

. WASHER, OIL SEAL

464-23146-00-00

1
Out of stock

9

. SEAT, SPRING LOWER

164-23143-00-00

1
Out of stock

10

. SPRING, FRONT FORK

164-23141-00-00

1
Out of stock

11

. SEAT, SPRING UPPER

164-23142-00-00

1
Out of stock

12

. UNDER BRACKET

164-23340-00-33

1
Out of stock

13

. COVER, LOWER 1

164-23123-00-81

1
Out of stock

14

PACKING(LAMP STAY)

164-23163-00-00

1

$6.46

In stock

15

. GUIDE, COVER LOWER

164-23116-00-00

1
Out of stock

16

. COVER, UPPER 1

164-23121-00-81

1
Out of stock

17

. COVER, UPPER 2

164-23131-00-81

1
Out of stock

18

GASKET

307-23114-00-00

—
Out of stock

19

. WASHER, CAP

164-23112-00-00

1
Out of stock

20

. BOLT, CAP

164-23111-00-00

1
Out of stock

21

YBS67-10 WASHER, SPRING

92990-10100-00

—

$2.43

In stock

22

BOLT 1

122-23346-02-00

—

$6.25

In stock

23

YBS67-8 WASHER, SPRING

92990-08100-00

—

$4.52

In stock

24

BOLT, HEXAGON

97017-08025-00

—

$7.46

In stock

25

RACE, BALL 2

B6E-23412-00-00

—

$9.71

In stock

26

BALL

93501-04011-00

—
Out of stock

27

RACE, BALL 1

B6E-23411-00-00

—

$7.02

In stock

28

SEAL, DUST

164-23462-00-00

—

$6.42

In stock

29

RACE, BALL 2

B6E-23412-00-00

—

$9.71

In stock

30

CROWN, HANDLE

183-23435-00-38

1
Out of stock

31

COVER, BALL RACE

136-23415-00-00

—

$7.71

In stock

32

NUT

90179-25004-00

—

$20.78

In stock

33

WASHER

90209-10020-00

—

$3.98

In stock

34

BOLT 1222345100

90105-10006-00

—

$9.17

In stock

35

HOLDER HANDLE UPR

164-23441-01-38

1
Out of stock

36

YBS67-8 WASHER, SPRING

92990-08100-00

—

$4.52

In stock

37

BOLT

97013-08035-00

—

$4.80

In stock

38

STEERING LOCK ASSEMBLY

137-23480-00-00

1
Out of stock

39

SCREW, FLAT

98707-06014-00

—
Out of stock

40

WASHER (688)

92990-08400-00

1

$3.46

In stock

41

WASHER, PLAIN

92990-08200-00

1

$2.56

In stock

42

BOLT, HEXAGON

97013-08020-00

—

$1.54

In stock

43

PLUG, BLIND

164-83319-00-00

1
Out of stock
