Yamaha YFZ350M (BANSHEE) 5FK6 2000 FRONT FENDER Diagram

#

Description
Price

1

FENDER,FRONT COMP. (RW)

2GU-W2151-91-00

Unavailable

1

FRONT FENDER COMP. (DEEP PURPLISH BLUE SOLID E)

2GU-W2151-B1-00

$402.41

2

SCREW(3JM)

90149-06306-00

$2.76

3

STAY, FENDER 1

2GU-21513-00-00

$41.49

4

BOLT, FLANGE

95817-06010-00

$3.65

5

SCREW(3JM)

90149-06306-00

$2.76

6

NUT, SELF-LOCKING

95617-06100-00

$2.17

7

STAY, FENDER 2

2GU-21514-00-00

$41.49

8

BOLT, FLANGE

95817-06010-00

$3.65

9

SCREW(3JM)

90149-06306-00

$2.76

10

NUT, SELF-LOCKING

95617-06100-00

$2.17

11

STAY 1

2GU-21587-10-00

Unavailable

12

BOLT, HEXAGON

97017-08016-00

$5.79

13

STAY 2

2GU-21588-10-00

$14.64

14

BOLT, HEXAGON

97017-08016-00

$5.79

15

NUT, SELF-LOCKING

95617-06100-00

$2.17

16

NUT, SELF-LOCKING

95617-06100-00

$2.17
