Yamaha YFM25XS (BEARTRACKER) 4XEL 2004 TRANSMISSION Diagram

#

Description
Price

1

MAIN AXLE ASSY

59V-17401-00-00

Unavailable

2

GEAR, 5TH PINION

24W-17151-02-00

$50.46

3

WASHER(59V)

90209-17285-00

$8.63

4

CIRCLIP (525)

93410-20038-00

$2.62

5

GEAR, 3RD PINION (22T)

59V-17131-00-00

Unavailable

6

GEAR, 4TH PINION (25T)

59V-17141-00-00

Unavailable

7

GEAR, 2ND PINION

15A-17121-00-00

$33.98

8

BEARING(1YW)

93306-20461-00

$33.41

9

OIL SEAL (5H0)

93101-15101-00

$10.06

10

BRG, R-B (7H4)

93306-20211-00

$22.05

11

DRIVE AXLE ASSY

24W-17402-00-00

Unavailable

12

GEAR,2ND WHEEL

29U-17221-01-00

Unavailable

13

GEAR, 4TH WHEEL

24W-17241-00-00

$51.65

14

GEAR, 3RD WHEEL

15A-17231-00-00

$75.95

15

GEAR, 5TH WHEEL

4BD-17251-00-00

$55.65

16

WASHER (5H0)

90209-18208-00

$6.74

17

CIRCLIP (537)

93410-22039-00

$6.17

18

GEAR, 1ST WHEEL (34T)

29U-17211-00-00

Unavailable

19

WASHER (30X)

90209-23241-00

$3.32

20

CIRCLIP (30X)

93410-26067-00

$7.42

21

WASHER, PLATE (4L0)

90201-154E8-00

$6.17

22

PLATE, BEARING

24W-17558-00-00

Unavailable

23

SCREW

90149-08013-00

$6.25

24

BRG, R-B (7H4)

93306-20211-00

$22.05
