Yamaha YFM125GW (GRIZZLY 125) 1C5D 2007 FRONT WHEEL Diagram

#

Description
Price

1

HUB, FRONT

1C5-25111-00-00

$197.86

2

BOLT, SERRATION

90114-10014-00

$2.74

3

SPACER, BEARING

2FJ-25117-00-00

$30.77

4

BEARING(2JN)

93306-00315-00

$27.16

5

OIL SEAL (21V)

93102-23275-00

$12.45

6

FRONT WHEEL COMP.

3FA-25180-00-35

$207.98

7

NUT(2HR)

90179-10540-00

$3.92

8

TIRE (AT20X7-8 DI-K635A T/L)

94107-08009-00

$123.31

9

VALVE, RIM(2GH)

93900-00030-00

$14.46

10

COLLAR

90387-175R2-00

$10.02

11

WASHER PLATE 248181370000

90201-14220-00

$6.17

12

NUT, CASTLE(2UJ)

90171-14056-00

$10.57

13

PIN, COTTER

91401-30025-00

$6.18

14

PLATE, BRAKE SHOE

3FA-25121-00-00

Unavailable

15

BRAKE SHOE KIT

4BE-W253E-00-00

$22.27

16

SPRING, TENSION

90506-15260-00

$5.75

17

CAMSHAFT

5G3-25351-02-00

$17.25

18

LEVER, CAMSHAFT 1

3FA-25155-00-00

$26.82

19

BOLT, HEXAGON (538)

90101-06278-00

$1.82

20

NUT(6TA)

95317-06600-00

$2.69

21

PLATE, INDICATOR

52H-2513A-00-00

$1.91

22

O-RING(3LD)

93210-12790-00

$5.75

23

OIL SEAL(3BC)

93106-40027-00

$13.22

24

PLATE, BRAKE SHOE 2

3FA-25169-00-00

Unavailable

25

BRAKE SHOE KIT

4BE-W253E-00-00

$22.27

26

SPRING, TENSION

90506-15260-00

$5.75

27

CAMSHAFT

5G3-25351-02-00

$17.25

28

LEVER, CAMSHAFT 2

3FA-25156-00-00

$15.38

29

BOLT, HEXAGON (538)

90101-06278-00

$1.82

30

NUT(6TA)

95317-06600-00

$2.69

31

PLATE, INDICATOR

52H-2513A-00-00

$1.91

32

O-RING(3LD)

93210-12790-00

$5.75

33

OIL SEAL(3BC)

93106-40027-00

$13.22
